Royal Enfield Himalayan User Manual

Royal Enfield Himalayan
24
OPERATION OF CONTROLS
IGNITION KEY
NOTE
 Key can be removed only if ignition is in OFF or
steering is locked.
 Key is common for ignition, fuel tank lock, steering lock
and pillion seat.
 Key can be removed from fuel tank and pillion seat
only in locked position from the key slots.
WARNING
 Do not switch OFF ignition while riding the motorcycle.
 Doing so can cause a potential accident, resulting in
serious injury to both rider and other road users,
besides causing severe damage to the motorcycle.
STEERING LOCK
 Turn the handle bar to extreme left position.
 Push the key inside at OFF position, press and further
turn to anticlockwise direction to lock the steering
system.
 Turn the key in the clockwise direction to unlock the
steering.
“OFF”
“ON”

Royal Enfield Himalayan Specifications

General

Engine Type	Single Cylinder, 4 stroke, Air cooled, SOHC
Displacement	411 cc
Max Power	24.3 bhp @ 6500 rpm
Max Torque	32 Nm @ 4000 - 4500 rpm
Fuel System	Electronic Fuel Injection
Transmission	5-speed constant mesh
Front Suspension	Telescopic, 41 mm forks, 200 mm travel
Rear Suspension	Monoshock with linkage, 180 mm wheel travel
Front Brake	300 mm disc, 2-piston floating caliper
Fuel Tank Capacity	15 liters
Seat Height	800 mm
Ground Clearance	220 mm
Kerb Weight	199 kg
Bore x Stroke	78 mm x 86 mm
Compression Ratio	9.5:1
Clutch	Wet, multi-plate
Frame Type	Half-duplex split cradle frame
Tyre Size (Front)	90/90 - 21
Tyre Size (Rear)	120/90 - 17
Wheelbase	1465 mm
Rear Brake	240mm disc, single-piston floating caliper
ABS	Dual Channel ABS (Switchable)
