A–Display: Displays all the information relative to the menus on the board and the application in progress.
B– HOME button: In any context, if enabled, this allows the user to return immediately to the main screen. If
the button is enabled this is indicated by the corresponding back lighting.
C– BACK button: During navigation this button allows the user to return to the previous level in the menu
structure, while when any cycle is in progress, it allows the user to modify the control parameters of the
process in progress, temporarily saving the modified values.
D– Knob: The clockwise and anticlockwise turning of the knob allows the user to navigate through the
various menus on the display, while pressing it allows access to the selected item.
The RGB LED bar, built into the door handle or on the dashboard, takes on a different colour depending on
the process in progress:
- Stand-by: low intensity steady light blue light
- Chilling/freezing cycle (including infinity, Multy) Defrost and Cooling, in progress: high intensity flashing
light blue light
- Conservation in progress: high intensity steady light blue light
- Freezing in progress: high intensity steady red light
- Sanitising in progress: low intensity steady red light
- Fault: steady yellow light
