8000m Series
- 56 -
Chapter 5 Function Parameter Description
5.1 F0 Group—Basic Function
Select one operation mode for the drive.
0: Reserved
1: V/F control
V/F control is suitable to applications which do not require high accuracy of torque
and speed control, such as fans and pumps etc. In those applications, a VFD can
drive multiple motors simultaneously.
Select the channel of the control command of the VFD.
The control command of a VFD includes: start, stop, forward, reverse and jogging.
0: keypad
The command of start and stop can be executed through the key of RUN/STOP on
the keypad.
1: terminals
The VFD is controlled by multi-function digital input terminals M1～M4.
2: communications
F0.00
Control Mode Selection Factory Setting 1
Setting
Options
0 Reserved
1 V/F control
F0.01
Control command source Factory Setting 0
Setting
Options
0 Keypad
1 Terminals
2 Communication (RS485)
