R5 Series
- 29 -
Figure 5.3 Electrical interface of R5-7K/8K-S2
Code
Name
A
DC Switch
B
Decompression Valves
C
DC Input
D
RS232 Communication(GPRS/Wi-Fi/4G)
E
RS485 Communication
F
Ground Connection
G
AC Output
Table 5.3 Specifications for interface
