R5 Series
6.2 Monitoring Operation
● There is no LCD display screen in R5 series products and they could be monitored
through eSolar APP.
● This equipment is standardly equipped with a USB interface which could transfer
GPRS/4G module(with built-in Bluetooth) and Wi-Fi module to monitor running
state of the equipment.
6.2.1 APP Introduction
eSolar could achieve communication with the equipment via Bluetooth, GPRS/4G
and Wi-Fi and it is an APP for nearby and remote monitoring.
Download APP
Installers using iOS system could search for “eSolar O&M” in App Store and
download this App.
Installers using Android system could search for “eSolar O&M” in Google play and
download this App.
For iOS/Android system, installers could visit SAJ eSolar O&M Portal:
https://fop.saj-electric.com and scan the QR code to download eSolar O&M APP.
Account---Please use the installer account to login.
Note: For the end user, please download and install the “eSolar Air” APP and log in
to the APP or SAJ eSolar O&M Portal to register your account.
6.2.2 Nearby Monitoring
Connecting way 1 — Bluetooth connection
After installing the eSolar GPRS/4G module(with built-in Bluetooh) the mobile
phone could be directly connected with the inverter via Bluetooth.
Figure 6.2 Bluetooth connection schematic diagram
