INSTALLATION
Please read the important safety information at the start of this manual
before you begin to install the thermostat.
The ideal position to locate the RT500 thermostat is about 1.5m above floor
level, in a location where the thermostat is accessible, reasonably lit and
free from extremes of temperature and draughts. Do not mount the
thermostat on an outside wall, above a radiator or in a location where it
may be subjected to direct sunlight.
The electrical connections to the RT500 are made to the supplied industry
standard backplate. This simplifies installation, as no connections are made
to the controller itself. Connection details are shown below - no Earth
connection is required for the correct and safe operation of the RT500, but
a parking terminal is provided to connect an Earth wire if one is present.
RT500 INSTRUCTION MANUAL
4
