2-5 Product Specifications
2-5-1 Outdoor Unit
Type EHS TDM PLUS(OUTDOOR UNIT) EHS TDM PLUS(OUTDOOR UNIT) EHS TDM PLUS(OUTDOOR UNIT) EHS TDM PLUS(OUTDOOR UNIT) EHS TDM PLUS(OUTDOOR UNIT) EHS TDM PLUS(OUTDOOR UNIT) EHS TDM PLUS(OUTDOOR UNIT) EHS TDM PLUS(OUTDOOR UNIT)
Model Name AE044MXTPEH/EU AE066MXTPEH/EU AE090MXTPEH/EU AE090MXTPGH/EU AE120MXTPEH/EU AE120MXTPGH/EU AE160MXTPEH/EU AE160MXTPGH/EU
System
Mode - Heat Pump (A2W) Heat Pump (A2W) Heat Pump (A2W) Heat Pump (A2W) Heat Pump (A2W) Heat Pump (A2W) Heat Pump (A2W) Heat Pump (A2W)
A2W
Condition #1.
(A7/W35)
*1
Capacity
Heating
W 4,400 6,600 9,000 9,000 12,000 12,000 16,000 16,000
Btu/h 15,000 22,500 30,700 30,700 40,900 40,900 54,600 54,600
Cooling
W 5,100 6,700 8,000 8,000 12,000 12,000 14,500 14,500
Btu/h 17, 400 22,900 27, 3 0 0 27,30 0 40,900 40,900 49,500 49,500
Power Input
Heating
W
930 1,470 2,120 2,120 2,720 2,720 3,950 3,950
Cooling 1,030 1,480 1,850 1,860 2,900 2,900 3,840 3,840
COP (Heating) W/W 4.73 4.49 4.25 4.25 4.41 4.41 4.05 4.05
EER (Cooling) W/W 4.95 4.53 4.32 4.30 4.14 4.14 3.78 3.78
A2W
Condition #2.
(A7/W35)
*2
Capacity
Heating
W 4,000 6,100 8,000 8,300 11,200 11,200 15,000 15,000
Btu/h 13,600 20,800
27,30 0 28,300 38,200 38,200 51,200 51,200
Cooling
W 3,500 4,500 5,600 5,700 8,600 8,600 10,300 10,300
Btu/h 11,90 0 15,400 19,100 19,400 29,300 29,300 35,100 35,100
Power Input
Heating
W
1,160 1,830 2,380 2,500 3,300 3,300 4,710 4,710
Cooling 1,030 1,420 1,790 1,750 2,790 2,790 3,590 3,590
COP Heating W/W 3.45 3.33 3.36 3.32 3.39 3.39 3.18 3.18
EER Cooling W/W 3.40 3.17 3.13 3.26 3.08 3.08 2.87 2.87
A2/W35
*3
Capacity Heating W 4,000 5,800 7,70 0 7,70 0 11,000 11,000 13,700 13,700
COP W/W 3.54 3.31 3.47 3.47 3.41 3.41 3.19 3.19
A-7/ W35
*3
Capacity Heating W 3,900 5,700 7,4 0 0 7,4 0 0 10,600 10,600 14,000 14,000
COP W/W 2.81 2.79 2.79 2.79 2.97 2.97 2.73 2.73
Field
Wiring
MCA A
18.0 20.0 22.0 10.0 28.0 10.0 32.0 12.0
MFA A
25.0 25.0 27. 5 16.1 35.0 16.1 40.0 16.1
Water Connections Water Flow Rate Min/Std/Max LPM 7.0/12.7/42.0 7.0/19.0/42.0 7.0/26.0/42.0 7.0/26.0/42.0 12.0/34.6/58.0 12.0/34.6/58.0 12.0/46.2/58.0 12.0/46.2/58.0
Refrigerant
Piping
Connections
Liquid pipe Φ, mm (inch) 9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 9.52 (3/8) 9.52 (3/8)
Gas pipe(A2W) Φ, mm (inch) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8)
Gas pipe(A2A) Φ, mm (inch) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8) 15.88 (5/8)
Piping length
(ODU-IDU)
Max.[Equiv.] m 30 30 30 30 70 70 70 70
Level difference
(IDU-IDU)
Max. m 20 20 20 20 30 30 30 30
Chargeless Length m 10 10 10 10 10 10 10 10
Type - R410A R410A R410A R410A R410A R410A R410A R410A
Factory Charging kg 2.6 2.6 2.4 2.4 3.5 3.5 3.5 3.5
Control Method - EEV EEV EEV EEV EEV EEV EEV EEV
Outdoor Unit
Power Supply Φ, #, V, Hz 1,2,220-240,50 1,2,220-240,50 1,2,220-240,50 3,4,380-415,50 1,2,220-240,50 3,4,380-415,50 1,2,220-240,50 3,4,380-415,50
Compressor Type - Rotary Comp Rotary Comp Rotary Comp Rotary Comp Rotary Comp Rotary Comp
Rotary Comp Rotary Comp
Fan
Type - Propeller Fan Propeller Fan Propeller Fan Propeller Fan Propeller Fan Propeller Fan Propeller Fan Propeller Fan
Discharge direction Horizontal Horizontal Horizontal Horizontal Horizontal Horizontal Horizontal Horizontal
Air Flow Rate
m³/min
45 47 67 67 103 103 123 123
Quantity
EA
1 1 1 1 2 2 2 2
Sound
Sound Pressure
Heating
dB(A)
47 48 51 51 52 52 55 55
Cooling
dB(A)
46 47 50 50 51 51 54 54
Sound Power
dB(A)
65 67 69 69 70 70 73 73
External
Dimension
Net Weight
kg
61 61 74 76 107 107 107 107
Shipping Weight
kg
64.5 64.5 82 84 115 115 115 115
Net Dimensions (WxHxD)
mm
880 x 793 x 310 880 x 793 x 310 940 x 998 x 330 940 x 998 x 330 940 x 1,420 x 330 940 x 1,420 x 330 940 x 1,420 x 330 940 x 1,420 x 330
Shipping Dimensions (WxHxD)
mm
1,023 x 911 x 413 1,023 x 911 x 413 995 x 1,178 x 426 995 x 1,178 x 426 995 x 1,598 x 426 995 x 1,598 x 426 995 x 1,598 x 426 995 x 1,598 x 426
Operating
Temp. Range
A2W
Heating
℃
-25~35 -25~35 -25~35 -25~35 -25~35 -25~35 -25~35 -25~35
Cooling
℃
10~46
10~46 10~46 10~46 10~46 10~46 10~46 10~46
D.Hot Water
℃
-25~43 -25~43 -25~43 -25~43 -25~43 -25~43 -25~43 -25~43
A2A
Heating
℃
-25~24 -25~24 -25~24 -25~24 -25~24 -25~24 -25~24 -25~24
Cooling
℃
10~46 10~46 10~46 10~46 10~46 10~46 10~46 10~46
NOTE
* Specifications may be subject to change without prior notice.
*1) A2W Condition #1 : (Heating) Water In/Out 30
℃ /35 ℃ , Outdoor Air 7 ℃ [DB]/6 ℃ [WB]; (Cooling) Water In/Out 23 ℃ /18 ℃ , Outdoor Air 35 ℃ [DB].
*2) A2W Condition #2 : (Heating) Water In/Out 40 ℃ /45 ℃ , Outdoor Air 7 ℃ [DB]/6 ℃ [WB]; (Cooling) Water In/Out 12 ℃ /7 ℃ , Outdoor Air 35 ℃ [DB].
*3) A2W Condition : (A2W35) Water In/Out -/35 ℃ , Outdoor Air 2 ℃ [DB]/1 ℃ [WB]; (A-7/W35) Water In/Out -/35 ℃ , Outdoor Air -7 ℃ [DB]/-(* Peak Capacity)
4) Select wire size based on the value of MCA
5) Sound pressure level is obtained in an anechoic room.
- Sound pressure level is a relative value, depending on the distance and acoustic environment.
- Sound pressure level may differ depending on operation condition.
- dBA = A-weighted sound pressure level
- Reference acoustic pressure 0 dB = 20uPa
6) Sound power level is an absolute value that a sound source generates.
- dBA = A-weighted sound power level
- Reference power : 1pW
- Measured according to ISO 3741
7) These products contain R410A (GWP=2,088) which is fluorinated greenhouse gas.
