General Overview
Samsung Electronics
17
Model Name AE200TNWTEH AE260TNWTEH
Power source V/Hz 1Φ, 220-240V~, 50Hz 1Φ, 220-240V~, 50Hz
Operation range
[Water]
Cooling °C 5~25 5~25
Heating °C 15~55 15~55
Sound Pressure
Cooling dB(A) 26 26
Heating dB(A) 26 26
Sound Power Heating dB(A) 40 40
Dimension (WxHxD)
Net mm 595 x 1800 x 700 595 x 1800 x 700
Gross mm 700 x 2000 x 780 700 x 2000 x 780
Weight
Net kg 137 147
Gross kg 149 159
Connection Pipe
(regrigerant)
Liquid Inch 3/8" 3/8"
Gas Inch 5/8" 5/8"
Connection Pipe (Floor
Heating)
Inlet mm 28 28
Outlet mm 28 28
Connection Pipe
(Domestic Hot water)
Inlet mm 22 22
Outlet mm 22 22
Water Pump
Model Name - UPMM25-9 .5 UPMM25-9 .5
Maker - Grundfos Grundfos
Max . Vol Flow m3/h 5 .5 5 .5
electric Heater Input Power W 2000 2000
Flow Sensor Set Point LPM 7 7
expansion Vessel Volume Liter 8 8
Pressure relief Valve
Size Inch BSPP Male 1/2" BSPP Male 1/2"
relief Pressure bar 2 .9 2 .9
VALVe GeAr eXPAN Pipe I .D mm Φ7 .94 Φ7 .94
Air Vent Valve Size Inch BSPP Male 3/8" BSPP Male 3/8"
Operating Outdoor
Temp range
Heating
°C
-25 ~ 35 -25 ~ 35
Cooling 10 ~ 46
10 ~ 46
DHW Water -25 ~ 43 -25 ~ 43
2-5-3 TANK INTEGRATED HYDRO UNIT
