Samsung AE160MXTPEH User Manual

General Overview
16
Samsung Electronics
2-5 Product Specifications (cont.)
Type
EHS TDM PLUS
(HYDRO UNIT)
EHS TDM PLUS
(HYDRO UNIT)
EHS TDM PLUS
(HYDRO UNIT)
EHS TDM PLUS
(HYDRO UNIT)
Model Name AE090MNYDEH/EU AE090MNYDGH/EU AE160MNYDEH/EU AE160MNYDGH/EU
Mode - Heat Pump (A2W) Heat Pump (A2W) Heat Pump (A2W) Heat Pump (A2W)
Power Supply Φ, #, V, Hz 1,2,220-240,50 3,4,380-415,50 1,2,220-240,50 3,4,380- 415,50
Capacity
Heating
W 4,400~9,000 9,000 12,000~16,000 12,000~16,000
Btu/h 15,000~30,700 30,700 40,900~54,600 40,900~54,600
Cooling
W 5,100~8,000 8,000 12,000~14,500 12,000~14,500
Btu/h 17,4 0 0 ~27,3 0 0 27, 300 40,900~49,500 40,900~49,500
Water
Connections
Water Flow Rate Min/Std/Max LPM 7/-/42 7/-/42 12/-/58 12/-/58
Water Pressure Max. bar Max 3.0 Max 3.0 Max 3.0 Max 3.0
Water Pipe
Inlet Φ, inch BSPP 1+1/4" BSPP 1+1/4" BSPP 1+1/4" BSPP 1+1/4"
Outlet Φ, inch BSPP 1+1/4" BSPP 1+1/4" BSPP 1+1/4" BSPP 1+1/4"
Leaving Water
Temperature
Heating °C 15~55 (H/P : 25~55) 15~55 (H/P : 25~55) 15~55 (H/P : 25~55) 15~55 (H/P : 25~55)
Cooling °C 5~25 5~25 5~25 5~25
Ref. piping
Connections
Liquid pipe Φ, mm (inch) 6.35 (1/4") 6.35 (1/4") 9.52 (3/8") 9.52 (3/8")
Gas pipe Φ, mm (inch) 15.88 (5/8") 15.88 (5/8") 15.88 (5/8") 15.88 (5/8")
Water Pump
Type -
Centrifurugal
(UPM3 25 -7.5)
Centrifurugal
(UPM3 25 -7.5)
Centrifurugal
(Stratos 25 1-9)
Centrifurugal
(Stratos 25 1-9)
Motor Input W 60 60 90 90
Number of Unit EA 1 1
1 1
Flow Switch Type - Magnetic, Decreasing Magnetic, Decreasing
Magnetic,
Decreasing
Magnetic,
Decreasing
Min. flow rates LPM 7 ± 1.5 7 ± 1.5 12 ± 1.5 12 ± 1.5
Electric Expantion Vavle - EDM Φ3.2 EDM Φ3.2 EDM Φ4.0 EDM Φ4.0
Electric Heater W 4,000 6,000 6,000 6,000
Expansion Vessel Liter 8 8 8 8
Pressure Relief Valve bar 2.9 2.9 2.9 2.9
Air Purge Valve Ф, inch BSPP male 3/8" BSPP male 3/8" BSPP male 3/8" BSPP male 3/8"
Service Valve Ф, inch BSPP male 1 1/4" BSPP male 1 1/4" BSPP male 1 1/4" BSPP male 1 1/4"
Sound
Sound Pressure
Heating dB(A) 31 31 38 38
Cooling dB(A) 31 31 38 38
Sound Power dB 48 48 55 55
External
Dimension
Net Weight kg 45.5 46.5 46.5 46.5
Shipping Weight kg 55.0 56.0 56.0 56.0
Net Dimensions (WxHxD) mm 510 x 850 x 315 510 x 850 x 315 510 x 850 x 315 510 x 850 x 315
Shipping Dimensions (WxHxD) mm 564 x 1,024 x 412 564 x 1,024 x 412 564 x 1,024 x 412 564 x 1,024 x 412
NOTE
* Specifications may be subject to change without prior notice.
2-5-2 Hydro Unit
