Samsung Electronics 47
3-14. Error on EVI (ESC) OUT temperature sensor.(Short or open) (E-322)
Outdoor unit Display E-322
Indoor unit Display
Duct, Cassette (1 / 2Way), Console, Ceiling
Operation Defrost Timer Fan Filter / MPI
◑ × ×
◑
×
Cassette (4Way / Mini 4Way)
Operation Defrost Timer Filter
◑ ×
◑
×
Duct, Cassette (1/2 Way), Console, Ceiling
Operation Timer Turbo 24°C 27°C
◑ × ×
◑
×
※ ● : ON ◑ : Flash ×: OFF
Judgement Method t3FGFSUIFOFYUQBHF
Cause of problem t%JTDPOOFDUJPOPSCSFBLEPXOPGSFMFWBOUTFOTPS
Temperature(°C) Resistance(K)
70 2.2
60 3.0
50 4.2
40 5.8
30 8.3
20 12.1
10 18.0
0 27.3
-10 43.0
Did the connector for
the EVI In Temperature sensor break away
from the PCB?
Separate the connector of the Outdoor EVI In
Temperature sensor from the PCB and measure
the resistance value between the 2 terminals.
Did the resistance
value signicantly stray from the following
temperature table?
Restart operation after replace the PCB.
Restart operation after connecting
the connector to PCB.
Replace this part as it is the defective of the
outdoor EVI out temperature sensor itself.
Yes
No
Yes
No
