104
Screen Burn Pr
otection
Timer
Immediate Display
Side Gray
Pixel Shift
O
O
O
O
-
The displayed image may differ depending on the model
.
I
mmediate
D
ispla
y
Select the screen saver you want to display immediately
.
•
Off
/
Pixel
/
Rolling Bar
/
F
ading Screen
S
ide
G
ray
When the screen is set to
4:3
aspect ratio, adjust the brightness of white marg
ins on sides to protect the screen.
•
Off
/
Light
/
Dark
103
105
Table of Contents
Default Chapter
2
Table of Contents
2
Before Using the Product
6
Copyright
6
Safety Precautions
7
Symbols
7
Cleaning
7
Storage
8
Electricity and Safety
8
Installation
9
Operation
11
Preparations
15
Checking the Components
15
Components
15
Parts
16
Control Panel
16
Reverse Side
18
Reverse Side
19
Anti-Theft Lock
20
Remote Control
21
Before Installing the Product (Installation Guide)
23
Switching between Portrait and Landscape
23
Ventilation
23
Installing the Wall Mount
24
Preparing before Installing Wall-Mount
24
Installing the Wall Mount Kit
24
Wall Mount Kit Specifications (VESA)
25
Remote Control (RS232C)
26
Cable Connection
26
Connection
29
Control Codes
30
Power Control
31
Volume Control
31
Connecting and Using a Source Device
39
Before Connecting
39
Pre-Connection Checkpoints
39
Connecting to a PC
39
Connection Using the D-SUB Cable (Analog Type)
39
Connection Using a DVI Cable (Digital Type)
40
Connection Using an HDMI-DVI Cable
40
Connection Using an HDMI Cable
41
Connecting to a Video Device
42
Connection Using the AV Cable
42
Connection Using the Component Cable
42
Connection Using an HDMI-DVI Cable
43
Connection Using an HDMI Cable
44
Connecting to an Audio System
44
Connecting the Antenna
45
Connecting the LAN Cable
45
Connecting the Hdbase-T
46
Changing the Input Source
47
Source
47
Using MDC
48
MDC Program Installation/Uninstallation
48
Installation
48
Uninstallation
48
Connecting to MDC
49
Using MDC Via RS-232C (Serial Data Communications Standards)
49
Using MDC Via Ethernet
50
Screen Adjustment
51
Picture Mode
51
If the Input Source Is PC, DVI, HDMI(PC)
51
If the Input Source Is TV, AV, Component, HDMI(AV)
51
Backlight / Contrast / Brightness / Sharpness / Color / Tint (G/R)
52
Gamma
52
Calibrated Value
53
Picture Size
54
Position
55
Zoom/Position
55
Resolution Select
56
Auto Adjustment
56
PC Screen Adjustment
57
Pip
58
Pip Settings
58
Advanced Settings
59
Dynamic Contrast
60
Black Tone
60
Flesh Tone
60
RGB Only Mode
60
Color Space
60
White Balance
60
Motion Lighting
60
Picture Options
61
Color Tone
62
Color Temp
62
Digital Clean View
62
MPEG Noise Filter
62
HDMI Black Level
63
Film Mode
63
Auto Motion Plus
63
Dynamic Backlight
63
Picture off
64
Reset Picture
64
Sound Adjustment
65
Sound Mode
65
Sound Effect
66
Speaker Settings
67
Reset Sound
67
Broadcasting
68
Auto Program
68
Antenna
69
Channel List
70
Mode
70
Guide
71
Schedule Manager
71
Edit Channel
72
Edit Favorites
74
Channel Settings
77
Fine Tune
77
Clear Scrambled Channel
77
Audio Options
78
Preferred Language
78
Multi-Track Sound
78
Visual Impaired
78
Program Rating Lock
79
Caption
81
Digital Caption Options
82
Network
83
Network Status
83
Network Settings
83
Network Type
83
Network Settings (Wired)
84
Network Setting (Wireless)
86
Wps(Pbc)
88
Wi-Fi Direct
89
Allshare Settings
89
Server Network Settings
90
Connect to Server
90
Server Access
90
FTP Mode
90
Device Name
90
Source List
91
Refresh
91
Edit Name
91
Information
91
Magicinfo Lite
92
Playing Content from the Internal Memory or USB
92
Network Channel
93
Setup
95
Menu Language
96
Multi Control
96
Configuring Settings for Multi Control
96
Time
97
Clock
97
Sleep Timer
98
On Timer
98
Off Timer
99
Holiday Management
99
Eco Solution
100
Energy Saving
100
Eco Sensor
100
No Signal Power off
100
Auto Power off
100
Auto Protection Time
101
Screen Burn Protection
102
Pixel Shift
102
Timer
103
Immediate Display
104
Side Gray
104
Ticker
105
Video Wall
106
Format
106
Horizontal
106
Vertical
107
Screen Position
107
Source Autoswitch Settings
108
Source Autoswitch
108
Primary Source Recovery
108
Primary Source
108
Secondary Source
108
Change PIN
109
General
110
Max. Power Saving
110
Game Mode
110
Auto Power on
110
Safety Lock
110
Button Lock
111
Standby Control
111
HDBT Standby
111
Network Standby
111
Lamp Schedule
112
OSD Display
112
Power on Adjustment
112
Temperature Control
112
Anynet+ (HDMI-CEC)
113
Auto Turn off
114
Troubleshooting for Anynet
115
Clone Product
117
Reset System
117
Reset All
118
DIVX® Video on Demand
118
PC Module Power
118
Synced Power-On
118
Synced Power-Off
118
Support
119
Software Update
119
Update Now
119
Contact Samsung
119
Playing Photos, Videos and Music (Media Play)
120
Read the Following before Using Media Play with a USB Device
120
Using a USB Device
122
Menu Items in the Media Content List Page
123
Available Buttons and Features During Photo Playback
124
Available Buttons and Features During Video Playback
125
Available Buttons and Features During Music Playback
126
Supported Subtitle and Media Play File Formats
127
Subtitle
127
Compatible Image File Format
127
Supported Music File Formats
128
Supported Video Formats
128
Customer Service Center
131
Troubleshooting Guide
131
Requirements before Contacting Samsung Customer Service Center
131
Testing the Product
131
Checking the Resolution and Frequency
131
Check the Followings
132
Q & a
139
Specifications
140
General
140
Preset Timing Modes
142
(Cost to Customers)
144
Appendix
144
Responsibility for the Pay Service (Cost to Customers)
144
Not a Product Defect
144
A Product Damage Caused by Customer's Fault
144
Others
144
Optimum Picture Quality and Afterimage Burn-In Prevention
145
Optimum Picture Quality
145
Prevention of Afterimage Burn-In
145
License
147
Terminology
148
