Samsung ES60 User Manual

52
The Movie output signal from the camera can be NTSC or PAL.
Your choice of output will be governed by the type of device
(monitor or TV, etc.) to which the camera is connected. PAL
mode can support only BDGHI.

Connecting to an external monitor
When the camera is connected to an
external monitor, the image and menus
on the LCD monitor will be visible on the
external monitor and the LCD monitor of
the camera.
Selecting Video out type
Settings
(
”
)
- NTSC : U.S.A, Canada, Japan, South Korea, Taiwan, Mexico.
- PAL : Australia, Austria, Belgium, China, Denmark, Finland,
Germany, U.K., Holland, Italy, Kuwait, Malaysia, New
Zealand, Singapore, Spain, Sweden, Switzerland,
Thailand, Norway.
- When using a TV as an external monitor, you will need to select
the external or AV channel of the TV.
- There will be a digital noise on the external monitor, but it is not a
malfunction.
- If the image is not in the centre of the screen, use the TV controls
to centre it.
- When the camera is connected to an external monitor, some parts
of the image may not be displayed.
- When the camera is connected to an external monitor, the menu
will be visible on the external monitor and the menu functions are
the same as those indicated on the LCD monitor.
Back Set
AF Lamp :On
USB :Auto
Video Out :NTSC
NTSC
PAL
Yellow - Video
White - Sound

Samsung ES60 Specifications

General

Megapixel	12.3 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	1024 x 768, 1800 x 1200, 1920 x 1080, 2048 x 1536, 2592 x 1728, 2592 x 1944, 3264 x 2448, 3968 x 2232, 3984 x 2656
Digital zoom	3 x
Focal length range	6.3 - 18.9 mm
Digital SLR	No
Minimum RAM	256 MB
Minimum processor	Pentium III, PowerG3
Power supply type	DC
Aperture range (F-F)	3.2 - 5.8
Effective sensor resolution	12.2 pixels
Minimum storage drive space	250 MB
Minimum system requirements	USB CD-ROM
Compatible operating systems	Windows 2000/XP/Vista
Focal length (35mm film equivalent)	35 - 105 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 m
Auto focusing (AF) modes	Centre weighted Auto Focus
Macro focusing range (tele)	0.5 - 0.8 m
Macro focusing range (wide)	0.1 - 0.8 m
Normal focusing range (wide)	0.8 - ∞ m
Light metering	Centre-weighted, Spot
Flash modes	auto, fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 2 m
Flash range (wide)	0.2 - 3.75 m
Flash recharging time	4 s
Internal memory	11 MB
Compatible memory cards	sd, sdhc
Maximum memory card size	8 GB
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Product color	Gray
Scene modes	Backlight, beach, Children, Close-up (macro), Documents, dusk, Fireworks, Night, Portrait, self-portrait, Sunset, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	Negative film, Vivid
White balance	auto, Cloudy, custom modes, daylight, Fluorescent, Incandescent
Camera playback	movie, single image, slide show
Battery type	SLB-10A
Power requirements	4.2 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	21.6 mm
Width	90.4 mm
Height	59 mm
Weight	116 g
