Samsung ES60 User Manual

74
PictBridge : Reset
Initialises user-changed configurations.
1. Use the Up / Down buttons to select
the [Reset] menu tab. And then press
the Right button.
2. Use the Up / Down buttons to select
the desired sub menu value, and then
press the OK button.
If [Yes] is selected : All print and image settings will be reset.
If [No] is selected : Settings will not be reset.
Ä
Default print setting varies depending on the printer manufacturer.
For your printer’s default setting, refer to the user’s guide that
came with your printer.
Important notes
Be sure to observe the following precautions!

This unit contains precision electronic components. Do not use or
store this unit in the following locations.
- Areas exposed to severe changes in temperature and humidity.
- Areas exposed to dust and dirt.
- Areas exposed to direct sunlight or the inside of a vehicle in hot
weather.
- Environments where there is high magnetism or excessive vibration.
- Areas with high explosives or highly flammable materials.

Do not leave this camera in places subject to dust, chemicals (like
naphthalene and mothballs), high temperature and high humidity.
Keep this camera with silica gel in a hermetically sealed box when
not planning to use the camera for a long period of time

Sand can be particularly troublesome to cameras.
- Do not let sand get inside the camera when using it on beaches,
coastal dunes, or other areas where there is lots of sand.
- Doing so may result in failure or may permanently render the
camera unusable.

Handling the camera
- Never drop the camera or subject it to severe shocks or vibrations.
- Protect the large size LCD monitor from an impact. When this
camera is not used, keep it in the camera case.
- Avoid obstructing the lens or the flash when you capture an image.
- This camera is not waterproof.
To avoid dangerous electrical shocks, never hold or operate the
camera with wet hands.
- If you use this camera in wet places, such as beach or pool,
do not let water or sand get inside the camera. Doing so may
result in failure or may permanently damage the unit.
Back Set
File Name :Auto
Reset No
Date :Auto
Yes
No

Samsung ES60 Specifications

General

Megapixel	12.3 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	1024 x 768, 1800 x 1200, 1920 x 1080, 2048 x 1536, 2592 x 1728, 2592 x 1944, 3264 x 2448, 3968 x 2232, 3984 x 2656
Digital zoom	3 x
Focal length range	6.3 - 18.9 mm
Digital SLR	No
Minimum RAM	256 MB
Minimum processor	Pentium III, PowerG3
Power supply type	DC
Aperture range (F-F)	3.2 - 5.8
Effective sensor resolution	12.2 pixels
Minimum storage drive space	250 MB
Minimum system requirements	USB CD-ROM
Compatible operating systems	Windows 2000/XP/Vista
Focal length (35mm film equivalent)	35 - 105 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 m
Auto focusing (AF) modes	Centre weighted Auto Focus
Macro focusing range (tele)	0.5 - 0.8 m
Macro focusing range (wide)	0.1 - 0.8 m
Normal focusing range (wide)	0.8 - ∞ m
Light metering	Centre-weighted, Spot
Flash modes	auto, fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 2 m
Flash range (wide)	0.2 - 3.75 m
Flash recharging time	4 s
Internal memory	11 MB
Compatible memory cards	sd, sdhc
Maximum memory card size	8 GB
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Product color	Gray
Scene modes	Backlight, beach, Children, Close-up (macro), Documents, dusk, Fireworks, Night, Portrait, self-portrait, Sunset, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	Negative film, Vivid
White balance	auto, Cloudy, custom modes, daylight, Fluorescent, Incandescent
Camera playback	movie, single image, slide show
Battery type	SLB-10A
Power requirements	4.2 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	21.6 mm
Width	90.4 mm
Height	59 mm
Weight	116 g
