Samsung ES60 User Manual

95
FAQ

When the DirectX 9.0c or later is not installed

Install the DirectX 9.0c or later
1) Insert the CD provided with the camera
2) Run the windows explorer and select the [CD-ROM drive:\
DirectX] folder and click the DXSETUP.exe file.
The DirectX will be installed. Visit the following site for
downloading the DirectX.http://www.microsoft.com/directx

If a PC connected with the camera stops responding while
Windows is starting.

In this case, disconnect the PC and the camera and Windows
will start. If the problem happens continuously, set the Legacy
USB Support to disable and re-start the PC. The Legacy USB
Support is in the BIOS setup menu. (The BIOS setup menu
differs from the PC manufacturers and some BIOS menus don’
t have Legacy USB Support) If you can’t change the menu by
yourself, contact to the PC manufacturer or BIOS manufacturer.

If the movie clip can’t be deleted, or the removable disk can’t be
extracted or an error message displays during the file transfer.

If you install only the Samsung Master, the problems mentioned
above occasionally happen.
- Close the Samsung Master program by clicking the Samsung
Master icon on the Taskbar.
- Install all the application programs included in the software CD.
Correct disposal of batteries in this product
Correct disposal of batteries in this product
(Applicable in the European Union and other European
countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that
the batteries in this product should not be disposed of with other
household waste at the end of their working life. Where marked, the
chemical symbols Hg, Cd or Pb indicate that the battery contains
mercury, cadmium or lead above the reference levels in EC Directive
2006/66. If batteries are not properly disposed of, these substances
can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please
separate batteries from other types of waste and recycle them
through your local, free battery return system.
The rechargeable battery incorporated in this product is not user replaceable.
For information on its replacement, please contact your service provider.

Samsung ES60 Specifications

General

Megapixel	12.3 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Maximum image resolution	4000 x 3000 pixels
Still image resolution(s)	1024 x 768, 1800 x 1200, 1920 x 1080, 2048 x 1536, 2592 x 1728, 2592 x 1944, 3264 x 2448, 3968 x 2232, 3984 x 2656
Digital zoom	3 x
Focal length range	6.3 - 18.9 mm
Digital SLR	No
Minimum RAM	256 MB
Minimum processor	Pentium III, PowerG3
Power supply type	DC
Aperture range (F-F)	3.2 - 5.8
Effective sensor resolution	12.2 pixels
Minimum storage drive space	250 MB
Minimum system requirements	USB CD-ROM
Compatible operating systems	Windows 2000/XP/Vista
Focal length (35mm film equivalent)	35 - 105 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 m
Auto focusing (AF) modes	Centre weighted Auto Focus
Macro focusing range (tele)	0.5 - 0.8 m
Macro focusing range (wide)	0.1 - 0.8 m
Normal focusing range (wide)	0.8 - ∞ m
Light metering	Centre-weighted, Spot
Flash modes	auto, fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 2 m
Flash range (wide)	0.2 - 3.75 m
Flash recharging time	4 s
Internal memory	11 MB
Compatible memory cards	sd, sdhc
Maximum memory card size	8 GB
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
USB version	2.0
Product color	Gray
Scene modes	Backlight, beach, Children, Close-up (macro), Documents, dusk, Fireworks, Night, Portrait, self-portrait, Sunset, Landscape (scenery)
Image editing	resizing, rotating, trimming
Photo effects	Negative film, Vivid
White balance	auto, Cloudy, custom modes, daylight, Fluorescent, Incandescent
Camera playback	movie, single image, slide show
Battery type	SLB-10A
Power requirements	4.2 V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	21.6 mm
Width	90.4 mm
Height	59 mm
Weight	116 g
