21
Connection
Ensure you connect each of the adapters to the correct RS232C IN or OUT port on the product.
Connection 1
RS232C
IN OUT
RS232C
IN OUT
RS232C
IN OUT
RS232C
IN OUT
Connection 2
HDBT (LAN IN) HDBT (LAN IN)
Connection 3
RS232C
OUT
HDBT (LAN IN) RS232C
IN OUT
RS232C
IN OUT
RS232C
IN OUT
