Preset Timing Modes
This product can be set to only one resolution for each screen size to obtain the optimum picture quality due to the nature of the panel. Using a resolution other than the specified
resolution may degrade the picture quality. To avoid this, it is recommended that you select the optimum resolution specified for your product.
Model Name OH46B / OH46B-S
Synchronization Horizontal Frequency 15 – 135 kHz
Vertical Frequency 24 – 75 Hz
Resolution Optimum Resolution 1920 x 1080 @ 60 Hz
Maximum Resolution 4096 x 2160 @ 60 Hz
The screen will automatically be adjusted if a signal that belongs to the following standard signal modes is transmitted from your PC. If the signal transmitted from the
PC does not belong to the standard signal modes, the screen may be blank with the Power LED / Remote sensor on. In such a case, change the settings according to the
following table by referring to the graphics card user manual.
Resolution Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
IBM, 720 x 400 31.469 70.087 28.322 -/+
MAC, 640 x 480 35.000 66.667 30.240 -/-
MAC, 832 x 624 49.726 74.551 57.284 -/-
MAC, 1152 x 870 68.681 75.062 100.000 -/-
VESA, 640 x 480 31.469 59.940 25.175 -/-
VESA, 640 x 480 37.861 72.809 31.500 -/-
VESA, 640 x 480 37.500 75.000 31.500 -/-
VESA, 800 x 600 37.879 60.317 40.000 +/+
VESA, 800 x 600 48.077 72.188 50.000 +/+
– Horizontal Frequency
The time required to scan a single line
from the left to the right side of the
screen is called a horizontal cycle.
The reciprocal number of a horizontal
cycle is called horizontal frequency.
Horizontal frequency is measured in
kHz.
– Vertical Frequency
The product displays a single image
multiple times per second (like a
the viewer sees. The rate of a single
image being displayed repeatedly per
second is called vertical frequency
or refresh rate. Vertical frequency is
measured in Hz.
