Samsung SyncMaster 710MP User Manual

5. If you can see following message window, then click the
"Continue Anyway"
button. Then
click
"OK"
button.
6. Monitor driver installation is completed.
This monitor driver is under certified MS logo and this installation doesn't damage
your system.The certified driver will be posted on Samsung Monitor homepage.
http://www.samsung.com.
Windows XP | Windows 2000 | Windows Me | Windows NT | Linux
Installin
g
the Monitor Driver
(
Manual
)
When prompted by the operating system for the monitor driver, insert the CD-ROM included
with this monitor. Driver installation is slightly different from one operating system to
another. Follow the directions appropriate for the operating system you have.
Prepare a blank disk and download the driver program file at the Internet web site shown here.
z Internet web site : http://www.samsung.com (Worldwide)
http://www.samsung.com/monitor (USA)
http://www.sec.co.kr/monitor (Korea)
http://www.samsungmonitor.com.cn/ (China)
Microsoft
®
Windows
®
XP Operating System
1. Insert CD into the CD-ROM driver.
2. Click "
Start
" —> "
Control Panel
" then click the "
Appearance and Themes
" icon.
3. Click "
Display
" icon and choose the "
Settings
" tab then click "
Advanced..
".

Samsung SyncMaster 710MP Specifications

General

Pixel pitch	0.264 mm
Response time	12 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	31 - 81 kHz
Viewing angle, vertical	140 °
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Certification	TCO99
Product color	Silver
Market positioning	-
Bandwidth	0.135 GHz
I/O ports	15pin D-sub, S-video, Composite, RF
Power consumption (typical)	43 W
Package weight	6900 g

Weight and Dimensions

Depth (without stand)	206 mm
Width (without stand)	389 mm
Height (without stand)	402 mm
Weight (without stand)	5300 g
