Samsung SyncMaster 710MP User Manual

Terms
S
y
nc Si
g
nal
Sync (Synchronized) Signals refer to the standard signals that are required to display desired colors on
the monitor. They are divided into Vertical and Horizontal Sync Signals. These signals display normal
color images by the set resolution and frequency.
Types of Sync Signals
Separate This is a scheme of transmitting individual vertical and horizontal sync signals to
the monitor.
Composite This is a scheme of combining vertical and horizontal sync signals into one
composite signal and transmitting it to the monitor. The monitor displays the
color signals by separating the composite signal into original color signals.
Dot Pitch
The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the
resolution. The distance between two dots of the same color is called the 'Dot Pitch'. Unit: mm
Vertical Frequency
The screen must be redrawn several times per second in order to create and display an image for the
user. The frequency of this repetition per second is called Vertical Frequency or Refresh Rate. Unit: Hz
Example: If the same light repeats itself 60 times per second, this is regarded as 60 Hz.
Horizontal Frequency
The time to scan one line connecting the right edge to the left edge of the screen horizontally is called
Horizontal Cycle. The inverse number of the Horizontal Cycle is called Horizontal Frequency. Unit: kHz
Interlace and Non-Interlace Methods
Showing the horizontal lines of the screen from the top to the bottom in order is called the Non-
Interlace method while showing odd lines and then even lines in turn is called the Interlace method.
The Non-Interlace method is used for the majority of monitors to ensure a clear image. The Interlace
method is the same as that used in TVs.
Plug & Play
This is a function that provides the best quality screen for the user by allowing the computer and the
monitor to exchange information automatically. This monitor follows the international standard VESA
DDC for the Plug & Play function.
DVD
A
type of digital disk technology that takes up only the benefits of CD and LD, to implement a high
resolution/quality, which enables the user to enjoy clearer images.
DTV Broadcasting (Digital TV Broadcasting)
A
n enhanced broadcasting technology to process digital video signals using a set-top box, which
implements a high resolution and clearer digital images on the screen.
Resolution
The number of horizontal and vertical dots used to compose the screen image is called 'resolution'.
This number shows the accuracy of the display. High resolution is good for performing multiple tasks as
more image information can be shown on the screen.
Example: If the resolution is 1280 x 1024 , this means the screen is composed of 1280 horizontal
dots (horizontal resolution) and 1024 vertical lines (vertical resolution).
A2
This system uses two carriers to transmit voice data. Countries such as South Korea and Germany use
this system.
BTSC
Broadcast Television System Committee
The stereo broadcasting system that is used in most of the countries that have adopted the NTSC
system, including the United States, Canada, Chile, Venezuela and Taiwan. It also refers to the

Samsung SyncMaster 710MP Specifications

General

Pixel pitch	0.264 mm
Response time	12 ms
Display diagonal	17 \
Display resolution	1280 x 1024 pixels
Vertical scan range	56 - 75 Hz
Horizontal scan range	31 - 81 kHz
Viewing angle, vertical	140 °
Contrast ratio (typical)	600:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	160 °
Display brightness (typical)	300 cd/m²
Certification	TCO99
Product color	Silver
Market positioning	-
Bandwidth	0.135 GHz
I/O ports	15pin D-sub, S-video, Composite, RF
Power consumption (typical)	43 W
Package weight	6900 g

Weight and Dimensions

Depth (without stand)	206 mm
Width (without stand)	389 mm
Height (without stand)	402 mm
Weight (without stand)	5300 g
