7-3. Remote Control Unit Installation Position
The remote control unit can be operated from either a non-fixed position or a wall-mounted position.
To ensure that the air conditioner operates correctly, do not install the remote control unit in the following places:
In direct sunlight
Behind a curtain or other place where it is covered
More than 26' (8 m) away from the air conditioner
In the path of the air conditioner’s airstream
Where it may become extremely hot or cold
Where it may be subject to electrical or magnetic interference
Where there is an obstacle between the remote control unit and the air conditioner (since a check signal is sent
from the remote control unit every 5 minutes)
7-3-1. Mounting on a Wall
Before mounting the
remote control unit, press
the ON/OFF operation
button at the mounting
location to make sure that
the air conditioner
operates from that
location. The indoor unit
should make a beeping
sound to indicate that it
has received the signal.
Fig. 7
To take out the remote control unit, pull it forward.
Hole
Remote control unit mount
Rear side
Press
Set in
place
To prevent loss of the remote control
unit, you can connect the remote
control unit to the mount by passing
a string through the remote control
unit and attachment hole.
Mounting screws
5/32 × 5/8"(4 × 16mm)
(included)
To Next Page
