30
KEYSTONE button
Reduce the upper width with
Point e button.
Reduce the lower width
with Point d button.
Reduce the left part with
Point 7 button.
Reduce the right part with
Point 8 button.
• The white arrows indicate that there is no correction.
• A red arrow indicates the direction of correction.
• An arrow disappears at the maximum correction.
• If you press the KEYSTONE button on the remote
control again while the Keystone dialog box is being
displayed, the keystone adjustment will be canceled.
• The adjustable range can be limited depending on the
input signal.
• “Keystone” disappears after 10 seconds.
Press the P-TIMER button on the remote control. The
Timer display “00 : 00” appears on the screen and starts
to count time (00 : 00–59 : 59).
To stop the P-TIMER, press the P-TIMER button.
To cancel the P-TIMER, press the P-TIMER button again.
P-TIMER button
P-Timer display
Remote Control
P-TIMER
button
SHUTTER
button
✔Note:
•See the previous page for the description of
other buttons.
IMAGE ADJ.
button
Press the KEYSTONE button on the remote control. The
“Keystone” appears on the screen.
Use the Point ed7 8 buttons to correct keystone
distortion. The keystone adjustment can be stored
(pp.40, 44).
Basic Operation
KEYSTONE
button
IMAGE SEL.
button
Press the IMAGE ADJ. button on the remote control to
adjust a image level of the screen.
For more detail, see pp.45-47.
IMAGE ADJ. button
IMAGE SEL. button
Press the IMAGE SEL. button on the remote control to
select a desired image level of the screen.
For more detail, see pp.38, 42.
SHUTTER button
See page 27 for details.
FILTER button
Press and hold the FILTER button for more than five
seconds to replace the filter mechanically.
FILTER
button
✔Note:
•The filter cannot be rewound.
•
When the filter is replaced, the total accumulated time of
the filter use is automatically set to 0.
