Sanyo PLC-XU86 User Manual

-27-
Electrical Adjustments
Service Adjustment Data Table
These initial values are the reference data written from the
CPU ROM to memory IC when replaced new memory IC. The
adjustment items indicated with “
✻” are required to readjust fol-
lowing to the “Electrical adjustments”. Other items should be
used with the initial data value.
Item No. NAME Device
XGA
Range Description
PC/DVI/HDCP
Component Video
HDTV 480p 480i NTSC PAL
Group 0 AD9882
0 ADC G-OFFSET AD9882 55 55 -- PC/AV 30KHz/AV 15KHz
1 ADC R-OFFSET AD9882 55 55 -- PC/AV 30KHz/AV 15KHz
2 ADC B-OFFSET AD9882 55 55 -- PC/AV 30KHz/AV 15KHz
3 ADC G-GAIN AD9882 70 128 -- PC/AV 30KHz/AV 15KHz
4 ADC R-GAIN AD9882 70 128 -- PC/AV 30KHz/AV 15KHz
5 ADC B-GAIN AD9882 70 128 -- PC/AV 30KHz/AV 15KHz
6
10 VCO 0 Thresh MAX AD9882 42 Maximum frequency to select VCO 0
11 VCO 1 Thresh MAX AD9882 82 Maximum frequency to select VCO 1
20 CPC 0 Thresh MAX (VCO 0) AD9882 0 Maximum frequency to select CPC0 at VCO 0
21 CPC 1 Thresh MAX (VCO 0) AD9882 0 Maximum frequency to select CPC1 at VCO 0
22 CPC 2 Thresh MAX (VCO 0) AD9882 15 Maximum frequency to select CPC2 at VCO 0
23 CPC 3 Thresh MAX (VCO 0) AD9882 26 Maximum frequency to select CPC3 at VCO 0
24 CPC 4 Thresh MAX (VCO 0) AD9882 32 Maximum frequency to select CPC4 at VCO 0
25 CPC 5 Thresh MAX (VCO 0) AD9882 39 Maximum frequency to select CPC5 at VCO 0
26 CPC 6 Thresh MAX (VCO 0) AD9882 255 Maximum frequency to select CPC6 at VCO 0
30 CPC 0 Thresh MAX (VCO 1) AD9882 0 Maximum frequency to select CPC0 at VCO 1
31 CPC 1 Thresh MAX (VCO 1) AD9882 0 Maximum frequency to select CPC1 at VCO 1
32 CPC 2 Thresh MAX (VCO 1) AD9882 0 Maximum frequency to select CPC2 at VCO 1
33 CPC 3 Thresh MAX (VCO 1) AD9882 0 Maximum frequency to select CPC3 at VCO 1
34 CPC 4 Thresh MAX (VCO 1) AD9882 48 Maximum frequency to select CPC4 at VCO 1
35 CPC 5 Thresh MAX (VCO 1) AD9882 64 Maximum frequency to select CPC5 at VCO 1
36 CPC 6 Thresh MAX (VCO 1) AD9882 255 Maximum frequency to select CPC6 at VCO 1
40 CPC 0 Thresh MAX (VCO 2) AD9882 0 Maximum frequency to select CPC0 at VCO 2
41 CPC 1 Thresh MAX (VCO 2) AD9882 0 Maximum frequency to select CPC1 at VCO 2
42 CPC 2 Thresh MAX (VCO 2) AD9882 0 Maximum frequency to select CPC2 at VCO 2
43 CPC 3 Thresh MAX (VCO 2) AD9882 0 Maximum frequency to select CPC3 at VCO 2
44 CPC 4 Thresh MAX (VCO 2) AD9882 90 Maximum frequency to select CPC4 at VCO 2
45 CPC 5 Thresh MAX (VCO 2) AD9882 108 Maximum frequency to select CPC5 at VCO 2
46 CPC 6 Thresh MAX (VCO 2) AD9882 255 Maximum frequency to select CPC6 at VCO 2
60 PRECOAST (PC) AD9882 3
61 POSTCOAST(PC) AD9882 3
62 PRECOAST (PC Video) AD9882 10
63 POSTCOAST(PC Video) AD9882 4
64 PRECOAST (Component) AD9882 10 Maximum frequency to select CPC6 at VCO 3
65 POSTCOAST(Component) AD9882 4 Maximum frequency to select CPC7 at VCO 3
70 FREQ OFFSET AD9882 10
Group 1 UPD64012
0 Version (R) UPD64012 -- Read Only
1 Set Color (R) uPD64012 -- Read Only
2 SIGINF (R) uPD64012 -- Read Only
3 INTPRG (R) uPD64012 -- Read Only
4 HSLCK (R) uPD64012 -- Read Only
5 ISIGINF (R) uPD64012 -- Read Only
6 PSIGINF (R) uPD64012 -- Read Only
7 IMODE uPD64012 0
8 RGB_MIX uPD64012 0
9 AUTOCLR uPD64012 1
10 SIGDETLV uPD64012 1
11 SIGON uPD64012 1
12 SIGOFF uPD64012 0
13 TV50F uPD64012 0
14 TV60F uPD64012 0
15 SETINT uPD64012 1
16 SETPRG uPD64012 0
17 COLORM uPD64012 0
18 KILOFFT uPD64012 0
19 UNLINC uPD64012 0
20 DETOUT uPD64012 3
21 DETTIM uPD64012 3
22 CLKVA uPD64012 1
23 CLKKLL uPD64012 40
24 CODDEN uPD64012 0
25 CRDLY uPD64012 1
26 PHBDL uPD64012 0
27 PHRDL uPD64012 0
28 CBOFS uPD64012 0
29 CROFS uPD64012 0
30 FRCENY uPD64012 0
31 FRCENC uPD64012 0
