Sanyo PLC-XU86 User Manual

Control Port Functions
System Control I/O Port Functions (IC301)
PIN No. PIN NAME PORT SIGNAL DESCRIPTION I/O
82 D1 IN0RO5 PWR_LED POWER LED Drive On: H O
83 E1 IN0GO3 BLAST_AC Ballast Drive Power-On: H O
158
E2 IN0RO3 LAMPREP_LED LAMP REPLACE LED Drive On: H O
80 F1 IN0GO7 ON_3.3V 3.3V Drive On: H O
157
F2 IN0GO5 15V_ON 15V Drive On: H O
226 F3 IN0RO9 FAN_SW2 Fan Control Switch O
79 G1 IN0BO3 PANEL_OPT Panel Optioin H: XGA, L:SVGA I
225 G3 IN0GO9 FAN_K8N Fan Drive On: H O
286 G4 IN0RO6 CABLE_SW Cable Switch On: H O
78 H1 IN0BO7 NETWORK_OPT Network Option I
155
H2 IN0BO4 CARD_IN I
285 H4 IN0RO2 WARINIG_LED WARNING LED Drive On: H O
77 J1 IN0VS VS_AD_PW I
223 J3 IN0HS HS_AD_PW I
284 J4 IN0GO8 ON_5VA 5VA Drive On: H O
76
K1 IN0BO5 W_LAN_IN Wireless LAN Option I
153
K2 IN0CST GCOAST I
222 K3 IN0CLP GBLKSPL I
75 L1 IN0AHS GHS I
152
L2 IN0BO2 P_FAIL Power Failure Detection Input I
282 L4 IN0CLK CK_AD I
151
M2 MCI_ON O
81 M3 IN0RO8 FAN_SW1 Fan Control Switch O
73 N1 IN0GO6 LAMPDC_ON On: H O
72 P1 IN0GO2 DC_ON On: H O
149
P2 IN0RO4 READY_LED READY LED Drive On: H O
278 R4 IN1PEN VPEN I
216
T3 IN1R9 IRM_STB_PW
215
U3 IN1CLK VCLK I
327 V6 ADC2 KEY3 Key Input I
326 V7 XO XO O
316 V17
DCLK DCLK O
315 V18
DHS DHS O
258 V19 DVS DVS O
67 W1 IN1R3 SH_G_STB_PW O
144
W2 IN1R5 AUDIO_MUTE Audio Mute Output Mute-On: H O
274
W4 IN1R2 SH_R_STB_PW O
271 W7 XI XI I
269 W9 PORTA6 SDA3 I/O
268 W10 PORTA7 SCL3 O
266 W12 PORTB5 SCLK_PW O
265 W13 TXD TXD_PW Serial Control TXD O
66 Y1 TXD1 CHO_TXD Ballast Control TXD O
212
Y3 IN1FIELD VFIELD I
211
Y4 IN1VBI VBLK I
209 Y6 LVDSEN LVDSEN
207 Y8 NMI NMI I
206 Y9 PORTA0 SDA0 I/O
202 Y13 RXD RXD_PW Serial Control RXD O
65 AA1 IN1AHS VHS I
141
AA3 IN1R7 IRM_RST_PW O
140
AA4 RXD1 CHO_RXD Ballast Control RXD O
139
AA5 IN1R6 MONIT_OUT Monitor Out Switch Montor-Out: H O
138
AA6 ADC0 KEY1 Key Input I
136
AA8 RESETB RESET Reset Input I
135
AA9 PORTA3 SCL1 O
134 AA10 PORTA2 SDA1
I/O
63 AB2 IN1VS VVS I
60 AB5 IN1R4 SH_B_STB_PW O
59 AB6 IN1HS VHS I
58 AB7 ADC1 KEY2 Key Input I
56 AB9 PORTB4 SDATA_I/O I/O
55 AB10 PORTA5 SCL2 O
54 AB11 PORTA1 SCL0 O
53 AB12 PORTA4 SDA2 I/O
52 AB13 IRRCVR0 RC Remote Contro Signal Input I
