13
Installation
✔ Notes:
• The brightness in the room has a great influence on picture quality. It is recommended to limit ambient
lighting in order to obtain the best image.
• The values shown below are approximate and may vary from the actual sizes.
Positioning the Projector
32.8' (10.0 m)
17.7' (5.4 m)
13.4' (4.1 m)
8.9' (2.7 m)
A : B = 6 : 1
(Inch Diagonal)
3.6' (1.1 m)
For projector positioning, see the figures below. The projector should be set horizontally to the flat screen.
(Center)
Projection angle can be adjusted up to 10.0 degrees with
the adjustable foot.
Lift the front of the projector and push the foot lock
latch on the projector.
1
Adjustable Foot
Foot Lock Latch
Release the foot lock latch to lock the adjustable foot
and rotate the adjustable foot to adjust the position and
tilt.
To retract the adjustable foot, lift the front of the
projector and push and undo the foot lock latch.
Keystone distortion of the projected image can be
corrected by menu operation. (p.23, 47)
Adjustable Foot
2
3
Screen Size
(W x H) mm
4 : 3 aspect ratio
Zoom (max)
40"
Zoom (min)
813 x 610
3.6' (1.1 m)
100"
2032 x 1524
8.9' (2.7 m)
10.8' (3.3 m)
150"
3048 x 2286
13.4' (4.1 m)
16.4' (5.0 m)
200"
4064 x 3048
17.7' (5.4 m)
22.0' (6.7 m)
300"
6096 x 4572
26.9' (8.2 m)
32.8' (10.0 m)4.3' (1.3 m)
40"
100"
150"
200"
300"
81"
123"
162"
246"
26.9' (8.2 m)
Min. ZoomMax. Zoom
