Sanyo PLV-Z4 Service Manual

-60-
40 LINE_R2 1 0 - 255
41 LINE_R3 0 0 - 255
42 LINE_R4 0 0 - 255
43 LINE_G0 4 0 - 255
44 LINE_G1 3 0 - 255
45 LINE_G2 1 0 - 255
46 LINE_G3 0 0 - 255
47 LINE_G4 0 0 - 255
48 LINE_B0 4 0 - 255
49 LINE_B1 3 0 - 255
50 LINE_B2 1 0 - 255
51 LINE_B3 0 0 - 255
52 LINE_B4 0 0 - 255
53 GHOST_R_Pos 6 0 - 15
54 GHOST_G_Pos 6 0 - 15
55 GHOST_B_Pos 6 0 - 15
56 GHOST_R_cent 0 0 - 2047
57 GHOST_R_start 128 0 - 2047
58 GHOST_R_end 128 0 - 2047
59 GHOST_G_cent 0 0 - 2047
60 GHOST_G_start 128 0 - 255
61 GHOST_G_end 128 0 - 255
62 GHOST_B_cent 0 0 - 2047
63 GHOST_B_start 128 0 - 255
64 GHOST_B_end 128 0 - 255
65 BLOCK_R1 0 0 - 2047
66 BLOCK_G1 0 0 - 2047
67 BLOCK_B1 0 0 - 2047
68 BLOCK_R2 0 0 - 2047
69 BLOCK_G2 0 0 - 2047
70 BLOCK_B2 0 0 - 2047
71 REVERSE_R 0 0 - 2047
72 REVERSE_G 0 0 - 2047
73 REVERSE_B 0 0 - 2047
74 BACK_CTALK_R_cent 0 0 - 2047
75 BACK_CTALK_R_start 128 0 - 255
76 BACK_CTALK_R_end 128 0 - 255
77 BACK_CTALK_G_cent 0 0 - 2047
78 BACK_CTALK_G_start 128 0 - 255
79 BACK_CTALK_G_end 128 0 - 255
80 BACK_CTALK_B_cent 0 0 - 2047
81 BACK_CTALK_B_start 128 0 - 255
82 BACK_CTALK_B_end 128 0 - 255
83 CS_COR 1 0 - 1
84 H_START 265 0 - 2047
85 V_START 8 0 - 2047
86 H_END 1545 0 - 2047
87 V_END 728 0 - 2047
88 R_MIN 466 0 - 1023
89 R_MID6 556 0 - 1023
90 R_MID5 609 0 - 1023
91 R_MID4 650 0 - 1023
92 G_MIN 466 0 - 1023
93 G_MID6 556 0 - 1023
94 G_MID5 609 0 - 1023
95 G_MID4 650 0 - 1023
96 B_MIN 466 0 - 1023
97 B_MID6 556 0 - 1023
98 B_MID5 609 0 - 1023
99 B_MID4 650 0 - 1023
100 R_MID3 679 0 - 1023
101 R_MID2 706 0 - 1023
102 R_MID1 733 0 - 1023
103 R_MAX 762 0 - 1023
104 G_MID3 679 0 - 1023
105 G_MID2 706 0 - 1023
106 G_MID1 733 0 - 1023
107 G_MAX 762 0 - 1023
108 B_MID3 679 0 - 1023
109 B_MID2 706 0 - 1023
110 B_MID1 733 0 - 1023
111 B_MAX 762 0 - 1023
112 H_OUTPUT_Pos 108 0 - 1023
113 OUTAREA_LEVEL 0 0 - 1023
114 FLICKER_ADJUST 0 0 / 2 0: Disable, 2: Flicker adjustment setting
115 FRC_BIT 1 0 - 1 10bit/12bit
116 FRONT_CTALK2_R_cent 0 0 - 2047
117 FRONT_CTALK2_R_start 126 0 - 255
118 FRONT_CTALK2_R_end 128 0 - 255
119 FRONT_CTALK2_G_cent 0 0 - 2047
120 FRONT_CTALK2_G_start 126 0 - 255
121 FRONT_CTALK2_G_end 128 0 - 255
122 FRONT_CTALK2_B_cent 0 0 - 2047
123 FRONT_CTALK2_B_start 126 0 - 255
No. Adjustment Item Initial Value Range Input source / Description
Electrical Adjustments
