Sanyo PLV-Z4 Service Manual

-70-
IC8201
VIDEO
DECODER
& A/D
IC8001
HDMI
RECEIVER
IC4401
COLOR
MANAGER
B-LCD PANEL G-LCD PANEL R-LCD PANEL
HDMI
COMPONENT-2COMPONENT-1COMPUTERHDMI
IC3401
SDRAM
IC4801
SUB CPU
R/C
DOOR
SW
DOOR
SW
FAN
SWITCHING
POWER
SUPPLY
LINE
FILTER
OPTICAL
BLOCK
PROJECTION
LENS
AC
100~240V
LAMP
BALLAST
LAMP
IC8841
TEMP.
SENSOR
IC801
FLASH ROM
D-SUB_15
LAMP IRIS
SLIDE DOOR
DIGITAL
RGB
ANALOG
RGB
Y
Y/C
CB
CR
Y
CB
CR
D4
KEY SW
Y/C
CV
Y,Cb,Cr
Y,Cb,Cr
R
G
B
FAN CONTROL
LED
DC POWER
SUPPLY LINES
STANDBY 5V
CV
IC1501
DAC
IC1391
EEPROM
TH901,902
THERMISTOR
PC_RGB
SOG
Y,Cb,Cr
SCAN
CONVERTER
IC301
SYSTEM
CONTROL
IC501
S&H
BLUE
IC531
S&H
GREEN
IC561
S&H
RED
IC2501
LEVEL
SHIFT
IC2531
LEVEL
SHIFT
IC2561
LEVEL
SHIFT
IC401
DIGITAL
GAMMA
S-VIDEO VIDEO
RGB_VREF/VMID
IC1821
O_EXP.
IC1801
BUFFER
IC1811
BUFFER
POWER KEY
LAMP COVER SW
IC871
COMPARATOR
POWER
FAIL
DC-DC
CONVERTER
Z4 CHASSIS OVER VIEW
LAMP_PWM
IRIS_PWM
LENS IRIS MOTOR
LAMP IRIS MOTOR
SERVICE
PORT
IC3801
RS-232C
INTERFACE
THERMAL SW
MAIN
SW
IC8701
MOTOR DRIVER
MM
SLIDE DOOR MOTOR
IC6551
MOTOR DRIVER
M
PC_H/V
SCART_CV
PC_H/V
FOR JAPAN
MODEL ONLY
IC7841
DAC
SWITCHING
POWER
SUPPLY
IC5201
YUV-SW
PRIMARY CIRCUIT
● Chassis Overview
■ Chassis Block Diagram
