Sanyo PLV-Z4 Service Manual

-83-
From previous
page
Troubleshooting
No picture with S-
VIDEO input source
Check Computer source input stage;
Check RGB signals at test points TP-RIN/GIN/BIN.
Check IC8201 and peripheral circuit.
Check sync signals at test points TPADHS and TPADVS.
No picture with
Computer (RGB analog)
input source
No picture with VIDEO
input source
No
No picture with
Computer (RGB SCART)
input source
No
Yes
Yes
No
SG: PC_RGB signals are sent to IC8201. They are A/D-converted in IC8201
and sent to IC301.
Sync: PC_HS/VS signals are sent to IC8201 via IC8271(Inverter IC) and ADHS
and ADVS signals are sent to IC301.
Check AV source input stage;
Check Y/C signals at IC8201, IC5231 and peripheral circuit.
Check sync signals at test points TPADHS and TPADVS.
Yes
SG: Y signal is selected in IC5231, with S/CV_SW signal(S-VIDEO = Low).
The selected signal is sent to IC8201. S_CHROMA signal is sent to
IC8201. They are A/D-converted in IC8201 and sent to IC301.
Sync: Y/C signals are sync-separated in IC8201, and ADHS and ADVS signals
are sent to IC301.
Check Computer source input stage;
Check RGB SCART signals at test points TP-RIN/GIN/BIN.
Check IC8201, IC5231 and peripheral circuit.
Check sync signals at test points TPADHS and TPADVS.
Yes
SG: RGB SCART signals are A/D-converted in IC8201 and sent to IC301.
Sync: SCART_CV signal at 13 pin of D-sub_15 is selected in IC5231, with
S/CV_SW signal(SCART = High). The selected signal is sent to IC8201. It
is sync-separated in IC8201, and ADHS and ADVS signals are sent to
IC301.
Check AV source input stage;
Check IC8201 and peripheral circuit.
Check sync signals at test points TPADHS and TPADVS.
SG: Composite video signal is sent to IC8201, and sent to IC301.
Sync: Composite video signal is sync-separated in IC8201, and ADHS and
ADVS signals are sent to IC301.
