2-3. Other Component Specifications
Models STW * * * * C2
Models STW * * * * H2
Electric Heater Ass'y (230/208 V) AH-T22 AH-T23 AH-T25
Model STW0622C2 STW0622C2 STW0623C2 STW0623H2
STW0922C2 STW0922H2 STW0923C2 STW0923H2 STW0925C2 STW0925H2
STW1222C2 STW1222H2 STW1223C2 STW1223H2 STW1225C2 STW1225H2
STW1522C2 STW1522H2 STW1523C2 STW1523H2 STW1525C2 STW1525H2
Heater element Rating (230 V) 2.55kw, 11.1A 3.45kW, 15.5A 5.00kW, 22.4A
(208 V) 2.09kw, 10.4A 2.82kW, 14.0A 4.09kW, 20.2A
Resistance Ω
18.86 ± 5% (at 68°F) 13.94 ± 5% (at 68°F) 19.24 ± 5% (at 68°F)
Watt density
w/in
2
37.8 33.4 36.4
Wire diameter In. Dia. 0.040 Dia. 0.051 Dia. 0.040
Straight length of wire Ft. Length 45.9 Length 53.8 Length 46.8
Heater thermo. Type 08-1866-00 08-2888-00 60TX01 08-2399-00 60TX01
(Thermal limit.) Operating temp. °F Open: 115 / Close: 95 Open: 125 / Close: 95 Open: 136 / Close: 105
Heater fuse Type 08-2429-072 08-2429-077 G5AM 08-2565-00 60FX04
Operating temp. °F Open: 162
Open:170 Open: 170
Electric Heater Ass'y (265 V) AH-T33 AH-T34 AH-T35
Model STW0633C2 STW0633H2 STW0634C2 STW0634H2
STW0933C2 STW0933H2 STW0934C2 STW0934H2 STW0935C2 STW0935H2
STW1233C2 STW1233H2 STW1234C2 STW1234H2 STW1235C2 STW1235H2
STW1534C2 STW1534H2 STW1535C2 STW1535H2
Heater element Rating (265 V) 3.00kw , 11.4A 4.00kW , 15.2A 5.00kW , 19.0A
Resistance Ω
21.28 ± 5% (at 68°F) 15.96 ± 5% (at 68°F) 25.54 ± 5% (at 68°F)
Watt density
w/in
2
39.4 40.6 27.4
Wire diameter In. Dia. 0.040 Dia. 0.048 Dia. 0.040
Straight length of wire Ft. Length 51.8 Length 54.7 Length 62.1
Heater thermo. Type 08-2110-00 08-2874-00 08-1866-00
(Thermal limit.) Operating temp. °F Open: 120 / Close: 90 Open: 135 / Close: 105 Open: 115 / Close: 85
Heater fuse Type 08-2873-00 08-1970-00 08-2867-00
Operating temp. °F Open: 160 Open: 170 Open: 160
Room Thermistor DTNTKS130B
Model Cooling & Heat Pump models
Resistance at 32°F kΩ 15±2%
Thermistor (Indoor coil) DTNTKS131B
Model Cooling & Heat Pump models
Resistance at 32°F kΩ 15±2%
Thermistor (Outdoor coil) DTNTKS133B
Model Heat Pump models
Resistance at 32°F kΩ 15±2%
Solenoid coil (for 4-way valve) STF-01AQ503UA1 STF-01AK501UA1
Model STW0622H2 / 0623H2 STW0633H2 / 0634H2
STW0922H2 / 0923H2 / 925H2 STW0933H2 / 0934H2
STW1222H2 / 1223H2 / 1225H2 STW1233H2 / 1234H2 / 1235H2
STW1522H2 / 1523H2 / 1525H2 STW1534H2 / 1535H2
Coil rating AC230/208V (60Hz), 6W AC265V (60Hz), 6W
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
