CHAPTER 4. MEMORY MAP
[1] MEMORY MAP
MODEL :
GA-7_IXC129WJN1
SEM PCD SOFTWARE GROUP TV DESIGN ENGINEERING TV PRODUCTION ENGINEERING
ISSUED DATE :1 MARCH 2007
ISSUED DATE : ISSUED DATE : 28.JUNE .2007
EEPROM CHECK DATA LIST 1
MANAGER MANAGER MANAGER
MATSUNAGA
CHIEF CHIEF CHIEF
ISMAIL
ENGINEER
Tan
ENGINEER ENGINEER
CHIN
SLAVE ADDRESS : A0(00-FF) A2(100-1FF) A4(200-2FF) A6(300-3FF) A8(400-4FF) AA(500-5FF) AC(600-6FF) AE(700-7FF)
ADDRESS DATA MICON EEPROM EEPROM CHASSIS CTV FINAL LAST INITIAL
(HEX) D7 D6 D5 D4 D3 D2 D1 D0 DEFAULT RANGE
WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE SETTING DATA
REMARK
00
EEPROM INITIALIZATION JUDGEMENT BYTE-0
7C 00-FF 7C
* depend on
Ixcode,
current this
model ix
IXC080 so
set as 7C 70
78 70.
01
EEPROM INITIALIZATION JUDGEMENT BYTE-1
70 00-FF 70
02
EEPROM INITIALIZATION JUDGEMENT BYTE-2
79 00-FF 79
03
EEPROM INITIALIZATION JUDGEMENT BYTE-3
78 00-FF 78
04
ROM VERSION
00 00-FF 00
05
SOFTWARE VERSION (HIGH BYTE)
01 00-FF 01
*depend on final
release version. If
version 0.70 so it
will become 00 & 46
06
SOFTWARE VERSION (LOW BYTE)
00 00-FF 00
07
FF
08
TUNING FREQUENCY (LOW BYTE)
00-FF FF
POS 0
09
TUNING FREQUENCY (HIGH BYTE)
00-FF FF
0A
TUNING FREQUENCY (LOW BYTE)
00-FF 5B
POS 1
0B
TUNING FREQUENCY (HIGH BYTE)
00-FF 07
0C
TUNING FREQUENCY (LOW BYTE)
00-FF BB
POS 2
0D
TUNING FREQUENCY (HIGH BYTE)
00-FF 10
0E
TUNING FREQUENCY (LOW BYTE)
00-FF D3
POS 3
0F
TUNING FREQUENCY (HIGH BYTE)
00-FF 11
10
TUNING FREQUENCY (LOW BYTE)
00-FF EB
POS 4
11
TUNING FREQUENCY (HIGH BYTE)
00-FF 12
12
TUNING FREQUENCY (LOW BYTE)
00-FF 03
POS 5
13
TUNING FREQUENCY (HIGH BYTE)
00-FF 14
14
TUNING FREQUENCY (LOW BYTE)
00-FF DB
POS 6
15
TUNING FREQUENCY (HIGH BYTE)
00-FF 2C
16
TUNING FREQUENCY (LOW BYTE)
00-FF 1B
POS 7
17
TUNING FREQUENCY (HIGH BYTE)
00-FF 29
18
TUNING FREQUENCY (LOW BYTE)
00-FF FB
POS 8
19
TUNING FREQUENCY (HIGH BYTE)
00-FF 2F
1A
TUNING FREQUENCY (LOW BYTE)
00-FF DB
POS 9
1B
TUNING FREQUENCY (HIGH BYTE)
00-FF 31
1C
TUNING FREQUENCY (LOW BYTE)
00-FF 93
POS 10
1D
TUNING FREQUENCY (HIGH BYTE)
00-FF 33
1E
TUNING FREQUENCY (LOW BYTE)
00-FF CF
POS 11
1F
TUNING FREQUENCY (HIGH BYTE)
00-FF 06
20
TUNING FREQUENCY (LOW BYTE)
00-FF E7
POS 12
21
TUNING FREQUENCY (HIGH BYTE)
00-FF 07
22
TUNING FREQUENCY (LOW BYTE)
00-FF 5F
POS 13
23
TUNING FREQUENCY (HIGH BYTE)
00-FF 12
24
TUNING FREQUENCY (LOW BYTE)
00-FF 77
POS 14
25
TUNING FREQUENCY (HIGH BYTE)
00-FF 13
26
TUNING FREQUENCY (LOW BYTE)
00-FF 8F
POS 15
27
TUNING FREQUENCY (HIGH BYTE)
00-FF 14
28
TUNING FREQUENCY (LOW BYTE)
00-FF DB
POS 16
29
TUNING FREQUENCY (HIGH BYTE)
00-FF 27
2A
TUNING FREQUENCY (LOW BYTE)
00-FF DB
POS 17
2B
TUNING FREQUENCY (HIGH BYTE)
00-FF 45
2C
TUNING FREQUENCY (LOW BYTE)
00-FF FF
POS 18
2D
TUNING FREQUENCY (HIGH BYTE)
00-FF FF
2E
TUNING FREQUENCY (LOW BYTE)
00-FF FF
POS 19
2F
TUNING FREQUENCY (HIGH BYTE)
00-FF FF
30
TUNING FREQUENCY (LOW BYTE)
00-FF FF
POS 20
31
TUNING FREQUENCY (HIGH BYTE)
00-FF FF
32
TUNING FREQUENCY (LOW BYTE)
00-FF 89
POS 21
33
TUNING FREQUENCY (HIGH BYTE)
00-FF 14
34
TUNING FREQUENCY (LOW BYTE)
00-FF 87
POS 22
35
TUNING FREQUENCY (HIGH BYTE)
00-FF 14
36
TUNING FREQUENCY (LOW BYTE)
00-FF 87
POS 23
37
TUNING FREQUENCY (HIGH BYTE)
00-FF 14
38
TUNING FREQUENCY (LOW BYTE)
00-FF 97
POS 24
39
TUNING FREQUENCY (HIGH BYTE)
00-FF 14
3A
TUNING FREQUENCY (LOW BYTE)
00-FF 85
POS 25
3B
TUNING FREQUENCY (HIGH BYTE)
00-FF 14
3C
TUNING FREQUENCY (LOW BYTE)
00-FF 99
POS 26
3D
TUNING FREQUENCY (HIGH BYTE)
00-FF 14
3E
TUNING FREQUENCY (LOW BYTE)
00-FF FF
POS 27
3F
TUNING FREQUENCY (HIGH BYTE)
00-FF FF
MODEL MODEL
LETTER NO. LETTER NO.
