Sharp 32SF56B User Manual

PRINTED WIRING BOARD ASSEMBLIES
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts Lists
and Schematic Diagrams. The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBE
R2. REF. NO.
3. PART NO.4. DESCRIPTION
in USA:Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
« MARK: SPARE PARTS-DELIVERY SECTION
p
MARK: X-RAY RELATED PARTS
PICTURE TUBE
(NOT REPLACEMENT ITEM)
MAIN UNIT
PWB-A: DUNTKD571WEB0
TUNER
NOTE:THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDETLY
Ref. No. Part No.  Description Code
SU V101 VB80ALB20X+1E X Picture Tube CX
RCILGA045WJZZ X Degaussing Coil AU
QEARCA006WJZZ X Ground-Part AG
PWB-A DUNTKD571WEB0 X MAIN Unit —
PWB-B DUNTKA527WEE4 X CRT Unit —
PWB-D DUNTKB572WEV0 X 2 LINE Y/C Unit —
Ref. No. Part No.  Description Code
TU1101 RTUDAA001WJQZ X Tuner BY
IC101 VHIPQ050ES1-1+ X PQ050ES1MXP AD
S U IC201 VHITB1253AN-1 X TB1253AN AT
U IC361 VHIAN5277//-1 X AN5277 AK
U IC501 VHITDA8177+-1 X TDA8177 AH
IC602 VHIBA15218F2EY X BA15218F AD
U IC701 VHITEA1533A-1 X TEA1533AP AH
U IC702 RH-FXA003WJZZ X PC123Y82 AC
S U IC703 VHISE135N++-F X I.C. AF
IC751 VHIPQ09RDA1-1 X PQ090RDA1SZ AE
IC900 VHICXA2089Q-2Y X CXA2089Q-6T AN
IC1101 VHIPQ1CZ41H-1Y X PQ1CZ41H2ZPH AG
IC1102 VHIBA00BC0W-1S X BA00BC0WT-V5 AF
IC1103 VHINJ2584AM-1Y X NJ2584AM AH
IC1104 VHIBA00BC0W-1S X BA00BC0WT-V5 AF
IC1403 VHIPQ05RDA1-1 X PQ050RDA1SZ AE
IC2001 RH-IXB644WJQ2Q X TMP88CS38BFG AR
IC2040 VHIKIA7045A-1+ X KIA7045AP AD
IC2101 VHIBR24L16F-1Y X BR24L16F AE
IC3001 VHICXA2194Q-1Y X CXA2194Q AS
IC3002 VHIBA15218F2EY X BA15218F AD
Q201 VS2SC2735//1EY X 2SC2735 AB
Q361 VS2SB709AR/-1Y X 2SB709AR AB
Q401 VS2SD601AR/-1Y X 2SD601AR AB
Q402 VS2SB709AR/-1Y X 2SB709AR AB
Q451 VS2SA1266-Y-1+ X 2SA1266(Y) AA
Q460 VSRT1N441C/-1Y X RT1N441C AA
Q471 VS2SD601AR/-1Y X 2SD601AR AB
Q472 VS2SD601AR/-1Y X 2SD601AR AB
Q473 VS2SD601AR/-1Y X 2SD601AR AB
Q601 VS2SC2482//-1+ X 2SC2482 AC
U Q602 VS2SC5931++-F X 2SC5931 AL
Q672 VS2SA1266-Y-1+ X 2SA1266(Y) AA
Q673 VS2SD1830//1E X 2SD1830 AF
U Q701 VSSPA11N603-1 X SPA11N603 AM
Q751 VS2SC3198-G-1+ X 2SC3198-G AA
Q754 VS2SC3198-G-1+ X 2SC3198-G AA
Q755 VS2SD601AR/-1Y X 2SD601AR AB
Q756 VS2SD601AR/-1Y X 2SD601AR AB
Q757 VS2SC3198-G-1+ X 2SC3198-G AA
Q758 VS2SA1266-Y-1+ X 2SA1266(Y) AA
Q781 VS2SD601AR/-1Y X 2SD601AR AB
Q782 VS2SD601AR/-1Y X 2SD601AR AB
Q802 VS2SD601AR/-1Y X 2SD601AR AB
Q901 VS2SD601AR/-1Y X 2SD601AR AB
Q902 VS2SD601AR/-1Y X 2SD601AR AB
Q903 VS2SD601AR/-1Y X 2SD601AR AB
Q904 VS2SD601AR/-1Y X 2SD601AR AB
Q905 VS2SD601AR/-1Y X 2SD601AR AB
Q906 VS2SD601AR/-1Y X 2SD601AR AB
Q907 VS2SD601AR/-1Y X 2SD601AR AB
Q908 VS2SB709AR/-1Y X 2SB709AR AB
Q910 VS2SB709AR/-1Y X 2SB709AR AB
Q2041 VS2SB709AR/-1Y X 2SB709AR AB
Q2042 VS2SB709AR/-1Y X 2SB709AR AB
Q2060 VS2SD601AR/-1Y X 2SD601AR AB
Q2201 VS2SD601AR/-1Y X 2SD601AR AB
Q2211 VS2SD601AR/-1Y X 2SD601AR AB
D103 RH-DX0441CEZZY X Diode AA
INTEGRATED CIRCUITS
TRANSISTORS
DIODES
27
32SF56B
