Sharp 32SF56B User Manual

PWB-A: DUNTKD571WEB0
MAIN UNIT
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
MISCELLANEOUS PARTS
Ref. No. Part No.  Description Code
RY701 RRLYJ0081CEZZ X Relay AE
RY702 RRLYJ0088CEZZ X Relay AE
TP701 QLUGP0102PEZZ X Test point AA
RMC2601 RRMCUA022WJZZ X R/C Receiver AE
U IC850 VHITDA6103Q-1 X TDA6103Q/N3 AK
Q850 VS2SA1266-Y-1+ X 2SA1266(Y) AA
Q851 VS2SC3198-G-1+ X 2SC3198-G AA
Q1504 VS2SC3198-G-1+ X 2SC3198-G AA
Q1505 VS2SA1266-Y-1+ X 2SA1266(Y) AA
Q1506 VS2SA2005++1E X 2SA2005E AD
Q1507 VS2SC5511++1E X 2SC5511E AD
D850 RH-DX0220CEZZY X DX0220CE AB
D851 RH-DX0220CEZZY X DX0220CE AB
D852 RH-DX0220CEZZY X DX0220CE AB
D853 RH-EX0647GEZZY X Zener Diode, 15V AB
D854 VHD1SS119//-1Y X Diode AA
D855 VHD1SS119//-1Y X Diode AA
D862 VHD1SS119//-1Y X Diode AA
D1502 VHD1SS119//-1Y X Diode AA
D1503 VHD1SS119//-1Y X Diode AA
D1506 RH-DX0487CEZZY X Diode AC
D1507 RH-DX0487CEZZY X Diode AC
D1510 VHD1SS119//-1Y X Diode AA
C850 VCFYSB2EB224K X 0.22 250V M.Poly. AC
C851 RC-KZ018JCEZZ X 0.01 AC250V Ceramic AB
C852 VCEA0A1CW107M+ X 100 16V EL. AA
C853 VCFYFA1HA224J+ X 0.22 50V Mylar AB
C854 VCEA0A1CW227M+ X 220 16V EL. AB
C855 VCEA0A2EW106M+ X 10 250V EL. AC
C856 VCEA0A1HW226M+ X 22 50V EL. AA
C1501 VCEA0A1CW476M+ X 47 16V EL. AA
C1506 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1508 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C1509 VCKYPA1HB472K+ X 4700p 50V Ceramic AA
C1510 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1511 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C1515 VCEA0A1HW476M+ X 47 50V EL. AB
C1516 VCEA0A1HW476M+ X 47 50V EL. AB
C1517 VCEA0A2AW106M+ X 10 100V EL. AB
C1518 VCCSPA2HL560K+ X 56p 500V Ceramic AB
C1519 VCEA0A2CW106M+ X 10 160V EL. AC
U R850 VRS-SV2HC152J X 1.5k 1/2W M-Ox. AA
U R851 VRS-SV2HC152J X 1.5k 1/2W M-Ox. AA
U R852 VRS-SV2HC152J X 1.5k 1/2W M-Ox. AA
U R853 VRS-SV2HC272J X 2.7k 1/2W M-Ox. AA
U R854 VRS-SV2HC272J X 2.7k 1/2W M-Ox. AA
U R855 VRS-SV2HC272J X 2.7k 1/2W M-Ox. AA
R856 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R857 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R858 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R861 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R862 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
PWB-B: DUNTKA527WEE4
CRT UNIT
INTEGRATED CIRCUITS
TRANSISTORS
DIODES
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
Ref. No. Part No.  Description Code
R863 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
R864 VRC-MA2HG152KY X 1.5k 1/2W Solid AB
U R867 VRS-SV2HC392J X 3.9k 1/2W M-Ox. AA
U R868 VRS-SV2HC682J X 6.8k 1/2W M-Ox. AA
R869 VRD-RA2BE103JY X 10k 1/8W Carbon AA
R870 VRD-RA2BE223JY X 22k 1/8W Carbon AA
R871 VRD-RA2BE472JY X 4.7k 1/8W Carbon AA
R872 VRD-RA2EE680JY X 68 1/4W Carbon AA
R873 VRD-RM2HD224JY X 220k 1/2W Carbon AA
R874 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R875 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R876 VRD-RM2HD104JY X 100k 1/2W Carbon AA
R877 VRD-RA2BE103JY X 10k 1/8W Carbon AA
U R878 VRS-SV2HC120J X 12 1/2W M-Ox. AA
R1511 VRD-RA2BE101JY X 100 1/8W Carbon AA
U R1513 VRS-VV3DB561J X 560 2W M-Ox. AA
R1514 VRD-RA2BE100JY X 10 1/8W Carbon AA
R1515 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1516 VRD-RA2BE820JY X 82 1/8W Carbon AA
R1517 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1518 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1519 VRD-RA2BE123JY X 12k 1/8W Carbon AA
R1520 VRD-RA2BE683JY X 68k 1/8W Carbon AA
R1521 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
R1525 VRD-RA2EE560JY X 56 1/4W Carbon AA
R1526 VRD-RA2EE560JY X 56 1/4W Carbon AA
R1527 VRD-RM2HD1R5JY X 1.5 1/2W Carbon AA
R1528 VRD-RM2HD1R5JY X 1.5 1/2W Carbon AA
U R1529 VRS-VV3DB221J X 220 2W M-Ox. AA
R1530 VRD-RA2BE122JY X 1.2k 1/8W Carbon AA
FB1501 RBLN-0020CEZZ+ X Ferrite Bead AB
P854 QPLGN0741CEZZ X plug (7 pins) AB
P860 QPLGN0841CEZZ X plug (8 pins) AB
U P861 QPLGN0241CEZZ X plug (2 PINS) AA
U RDA850 PRDAR0248PEFW X Heat Sink AD
RDA1506 PRDAR5072CEFW X Heat Sink AC
RDA1507 PRDAR5072CEFW X Heat Sink AC
SC850 QSOCV1011CEZZ X CRT Socket AE
IC1401 VHITC90A45F-1Y X TC90A45AF AM
Q1401 VS2SD601AR/-1Y X 2SD601AR AB
Q1402 VS2SD601AR/-1Y X 2SD601AR AB
Q1404 VS2SB709AR/-1Y X 2SB709AR AB
L1401 VP-XF100K0000Y X Peaking,10mH AA
L1402 VP-XF100K0000Y X Peaking,10mH AA
L1403 VP-XF100K0000Y X Peaking,10mH AA
L1404 VP-XF220K0000Y X Peaking,22mH AA
L1405 VP-XF220K0000Y X Peaking,22mH AA
L1408 VP-XF100K0000Y X Peaking,10mH AA
C1401 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1402 VCEA0A1AW227M+ X 220 10V EL. AB
C1403 VCCCCY1HH330JY X 33p 50V Ceramic AA
C1404 VCCCCY1HH181JY X 180p 50V Ceramic AA
C1405 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1406 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C1407 VCKYCY1HB103KY X 0.01 50V Ceramic AA
PWB-D: DUNTKB572WEV0
2 LINE Y/C UNIT
INTEGRATED CIRCUITS
TRANSISTORS
FERRITE BEAD
MISCELLANEOUS PARTS
FILTERS AND COILS
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
34
32SF56B
