PWB-A: DUNTKD571WEB0
MAIN UNIT
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
Ref. No. Part No.  Description Code
C368 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C369 VCEA0A1CW227M+ X 220 16V EL. AB
C370 VCEA0A1CW227M+ X 220 16V EL. AB
C371 VCEA0A1EW108M+ X 1000 25V EL. AC
C372 VCEA0A1EW108M+ X 1000 25V EL. AC
C373 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C375 VCEA0A1HW475M+ X 4.7 50V EL. AA
C429 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C433 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C434 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C435 VCEA0A1HW105M+ X 1 50V EL. AA
C436 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C437 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C438 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C439 VCEA0A1HW106M+ X 10 50V EL. AA
C440 VCFYFA1HA224J+ X 0.22 50V Mylar AB
C451 VCQYTA2AA104K+ X 0.1 100V Mylar AB
C452 VCEA0A1EW336M+ X 33 25V EL. AA
C471 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C473 VCCCCY1HH331JY X 330p 50V Ceramic AA
C474 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C475 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C476 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C501 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C502 VCEA0A1VW477M+ X 470 35V EL. AC
C504 VCEACA1HC474M+ X 0.47 50V EL. AC
C505 VCEA0A1HW474M+ X 0.47 50V EL. AA
C506 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C507 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C510 RC-FZ0272CEZZ+ X 0.39 100V Mylar AC
C512 VCEA0A1EW476M+ X 47 25V EL. AA
C514 VCEA0A1VW107M+ X 100 35V EL. AB
C516 VCKYCY1HB472KY X 100 35V EL. AA
C517 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C518 VCQYTA2AA104K+ X 0.1 100V Mylar AB
C522 VCFYFA1HA334J+ X 0.33 50V Mylar AB
C523 VCEA0A1HW105M+ X 1 50V EL. AA
C601 VCEA0A1CW108M+ X 1000 16V EL. AC
C602 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C603 VCEA0A1HW225M+ X 2.2 50V EL. AA
C604 VCKYCY1EB223KY X 0.022 25V Ceramic AA
C606 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C607 VCKYPA1HB472K+ X 4700p 50V Ceramic AA
C608 RC-KZ0033CEZZ X 150p 2kV Ceramic AB
S U C609 VCFPVC3ZA173H X 17000p 1800V M.Poly. AD
C610 RC-KZ0006TAZZ X 270p 2kV Ceramic AB
C611 VCEA0A1EW477M+ X 470 25V EL. AB
C614 VCEA0A1EW108M+ X 1000 25V EL. AC
C615 VCFYSB2EB823J X 0.082 250V M.Poly.. AB
C616 VCKYPA2HB471K+ X 470p 500V Ceramic AA
C617 VCEA0A1HW474M+ X 0.47 50V EL. AA
C622 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C623 VCEA4A2EN106M+ X 10 250V EL. AD
C652 VCEA0A1HW476M+ X 47 50V EL. AB
C653 VCEA0A1HW106M+ X 10 50V EL. AA
C674 VCKYCY1HB391KY X 390p 50V Ceramic AA
C675 VCEA0A1HW106M+ X 10 50V EL. AA
C677 RC-FZA178WJZZ X 4.7 63V M.Poly. AF
S U C678 VCQPPC2GB563J X 0.056 400V Mylar AC
C681 VCFPFA2EB514J X 0.51 250V M.Poly. AC
C682 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C685 VCQYTA1HM333J+ X 0.033 50V Mylar AA
C691 VCQYTA1HM682J+ X 6800P 50V Mylar AA
Ref. No. Part No.  Description Code
U C701 RC-FZA146WJZZ X 0.33 AC275V M.Poly. AC
C702 RC-KZ0029CEZZ+ X 0.01 AC250V Ceramic AB
C703 RC-KZ0029CEZZ+ X 0.01 AC250V Ceramic AB
U C705 RC-EZ0722CEZZ X 820 200V EL. AL
U C706 RC-KZ0089GEZZA X 1000p AC250V Ceramic AB
U C707 RC-KZ0092GEZZA X 3300p AC250V Ceramic AC
U C708 RC-FZA146WJZZ X 0.33 AC275V M.Poly. AC
U C723 RC-EZ0724CEZZ X 100 160V EL. AE
U C725 RC-EZA065WJZZ X 330 160V EL. AG
C726 RC-KZ0226CEZZ+ X 560p 2kV Ceramic AB
C727 RC-KZ0226CEZZ+ X 560p 2kV Ceramic AB
C729 VCEA0A1HW106M+ X 10 50V EL. AA
C730 VCEA4A1VN108M+ X 1000 35V EL. AD
C731 RC-EZ0385CEZZ+ X 1000 16V EL. AD
C732 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C733 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C734 VCKYPA2HB471K+ X 470p 500V Ceramic AA
C735 VCKYPA2HB471K+ X 470p 500V Ceramic AA
C736 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C737 VCEA0A1HW226M+ X 22 50V EL. AA
C738 VCFPVC3CA102H X 1000p 1250V M.Poly. AC
C739 RC-EZ0385CEZZ+ X 1000 16V EL. AD
C740 VCEA0A1HW476M+ X 47 50V EL. AB
C741 VCEA4A2AN105M+ X 1 100V EL. AB
C742 VCQYTA1HM683J+ X 68000p 50 Mylar AB
C743 RC-KZ0036CEZZ+ X 330p 2kV Ceramic AC
C744 VCKYPA2HB471K+ X 470p 500V Ceramic AA
C745 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C746 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C747 VCEA0A1HW475M+ X 4.7 50V EL. AA
C750 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C753 RC-KZ0036CEZZ+ X 330p 2kV Ceramic AC
C754 VCKYPA2HB472K+ X 4700p 500V Ceramic AB
C755 VCEA0A1EW476M+ X 47 25V EL. AA
C758 VCEA0A1HW475M+ X 4.7 50V EL. AA
C780 VCEA0A1HW226M+ X 22 50V EL. AA
C781 VCFYFA1HA105J+ X 1 50V M-Poly. AC
C782 VCKYCY1HB102KY X 1000p 50V Ceramic AA
C783 VCQYTA1HM103J+ X 0.01 50V Mylar AA
C784 VCKYCY1HF103ZY X 0.01 50V Ceramic AA
C790 VCEA4W1CN478M X 10 50 V EL. AE
C791 VCKYPA2HB102K+ X 1000p 500V Ceramic AA
C801 VCCCCY1HH110JY X 11p 50V Ceramic AA
C802 VCKYCY1HB222KY X 2200p 50V Ceramic AA
C803 VCEA0A1HW224M+ X 0.22 50V EL. AA
C804 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C805 VCEA0A0JW108M+ X 1000 6.3V EL. AB
C806 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C807 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C808 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C809 VCKYCY1CF104ZY X 0.1 16V Ceramic AA
C810 VCEA0A1CW477M+ X 470 16V EL. AB
C812 VCQYTA1HM104J+ X 0.1 50V Mylar AB
C901 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C902 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C903 VCKYCY1HB681KY X 680p 50V Ceramic AA
C904 VCEA0A1HW105M+ X 1 50V EL. AA
C905 VCEA0A1HW105M+ X 1 50V EL. AA
C906 VCKYCY1HB681KY X 680p 50V Ceramic AA
C907 VCEA0A1HW105M+ X 1 50V EL. AA
C908 VCKYCY1HB103KY X 0.01 50V Ceramic AA
C909 VCEA0A1HW105M+ X 1 50V EL. AA
C910 VCEA0A1HW105M+ X 1 50V EL. AA
C911 VCEA0A1HW105M+ X 1 50V EL. AA
C912 VCEA0A1HW105M+ X 1 50V EL. AA
C913 VCEA0A1HW105M+ X 1 50V EL. AA
C914 VCKYCY1HB681KY X 680p 50V Ceramic AA
C915 VCKYPA1HF103Z+ X 0.01 50V Ceramic AA
C916 VCKYCY1HB103KY X 0.01 50V Ceramic AA
29
32SF56B
