[3] KEY SCHEMATIC DIAGRAM
KEY2
SW021
TACT SW FWRD H1.5MM
R020
1.8K OHM 1/10W 5%
R021
4K3 1/10W 5%
R022
11KOHM +-5% 1/10W
C023
100N 50V
SW022
TACT SW FWRD H1.5MM
C016
NC/100N 50V
C017
NC/100N 50V
C018
NC/100N 50V
C019
NC/100N 50V
SW016
TACT SW FWRD H1.5MM
C020
NC/100N 50V
C021
NC/100N 50V
C022
NC/100N 50V
CN016
CONN 3P 1.25MM LOCK
1
2
3
45
KEY1
SW019
TACT SW FWRD H1.5MM
--------><-------|
C024
100N 50V
INPUT
-------><------|
----><----| ----><----| ----><----| ----><----|
----><----|
----><----|
SW020
TACT SW FWRD H1.5MM
----><----|
MENU
SW017 TACT SW FWRD H1.5MM
VOL- VOL+
SW018
TACT SW FWRD H1.5MM
CH- CH+
POWER
R017
4K3 1/10W 5%
R018
1.8K OHM 1/10W 5%
R019
470 OHM 1/10W
R016
11K 1/10W 5%
