LC-19LE320, LC-22LE320, LC-26LE320, LC-32LE320, LC-37LE320, LC-42LE320
218
CHAPTER 9. PARTS GUIDE
[1] SPARE PARTS LIST
Model: LC_19LE320E(AUO)(E19AA2NBWLXPNS)
Item TPV Code Number SHARP 13NC Description Quantity
54 Z12T 61007 9JR1200000007 Rubber foot 15*3t 7
55 P01G0022 1 9JR0100000060 SCREW(40x30L) 3
56 Q45T 99609 79 9JR4500000013 EPE COVER FOR BASE 1
57 0Q1G 130 6120 9JR0100000057 SCREW (T3X6) 7
60 705TZA3461A 9JR7050000146 KEY COVER ASSY 1
91 P34T0452PAT 1T0100 9JR3400000011 BASE_NECK 1
92 0M1T 340 10120 GP 9JR0100000068 SCREW 4
93 0Q1T 930 8120 9JR0100000059 SCREW 9
94 0M1T1730 6120 9JR0100000036 SCREW 3*6MM 14
95 0Q1G 330 5106 9JR0100000058 SCREW 6
96 0M1T 330 6120 9JR0100000056 SCREW 42A9930014 1
126 Z40G 19084305A 9JR4000000107 RATING LABEL 1
130 Z40G000184337A 9JR4000000119 CARTON LABEL 1
135 705TZA4106B 9JR7050000198 DFU ASSY(Western Europe)(Eastern Europe) 1
136 705TZA4107A 9JR7050000150 DFU ASSY(North Europe) 1
450 P44G9022843 2A 9JR4400000080 CARTON 1
451 P44G9022101 9JR4400000064 CUSHION_TOP 1
452 P44G9022201 9JR4400000065 CUSHION_BTM 1
453 P45G 46026 9JR4500000010 PE BAG(560X450-0.72mm) 1
456 050G 600 2 9JR5000000004 HANDLE1 1
457 050G 600 3 9JR5000000005 HANDLE2 1
504 P40TD000813 9A 9JR4000000005 family sheet 1
505 P40TD00081311A 9JR4000000006 FAMILY SHEET 1
1050 750GLU185X1634M0BQ 9JR7500000029 PANEL M185XW01 V60B SH 1
1053 CBPFA4ABP7 9JR9900000081 MAIN PCB ASSY(NUTUNE TUNER) 0
1054 ADTVA3615PA4 9JR9900000079 POWER PCB ASSY 1
1055 PTPFAPA5 9JR9900000068 Interface PCB Assy 1
1056 IRPFAPA4 9JR9900000059 IR PCB ASSY 1
1057 KEPFAPA1 9JR9900000060 KEY PCB ASSY 1
1172 089G204A15NLS1 9JR8900000009 POWER CORD 1.5M PE8C5Z1B90A-04B 1
1176 098GRABD2NESPJ 9JR9800000005 REMOTE CONTROL RC-SHARP-420 FOR SHARP 1
1185 078G035A 10 M 9JR7800000024 SPEAKER 16 OHM 3.5W 80X23 230/290 1
1185 078G035A 10 Y 9JR7800000025 SPEAKER 16 OHM 3.5W 80X23 230/290 0
1186 017G DW904 LY 9JR1700000001 LED MODULE LYSB-2811B 1
8401 095G801413F948 9JR9500000128 HARNESS 13P-5P+3P 320mm 1
8401 095G801413X948 9JR9500000131 HARNESS 13P-5P+3P 320mm 0
8408 095G801840F923 9JR9500000135 HARNESS 30P-40P 60mm 1
8408 095G801840X923 9JR9500000136 HARNESS 30P-40P 60mm 0
8802 095G176J 10919 9JR9500000094 FFC CABLE 10P 340mm P0.5 1
8901 095G8021 3F905 9JR9500000089 HARNESS AC INLET-3P 60mm 75549 1
705TZA1536A 9JR7050000211 MAIN FRAME ASSY 1
705TZA34126 9JR7050000218 BEZEL ASSY 1
705TZA34127 9JR7050000219 REAR COVER ASSY 1
705TZA3463A 9JR7050000148 BASE ASSY 1
1053 CBPFA4ABP8 9JR9900000082 MAIN PCB ASSY(LG TUNER) 1
C1000 067G215C4713LV 9JR6700000216 EC 470uF 20% 16V RXY 8*9 1
C1001 065G0805106A5K T 9JR6500000424 CHIP 10uF 10V X5R 0805 1
C1003 065G040210412K A 9JR6500000391 CAP CHIP 0402 100nF K 16V X7R 1
C1005 065G060327031J A 9JR6500000355 CAP CHIP 0603 27PF J 50V NPO 1
C1006 065G060327031J A 9JR6500000355 CAP CHIP 0603 27PF J 50V NPO 1
C1009 065G040210232K A 9JR6500000390 CAP 0402 1NF K 50V X7R 1
C1012 065G040247312K A 9JR6500000394 CAP CHIP 0402 47nF K 16V X7R 1
C1013 065G040247312K A 9JR6500000394 CAP CHIP 0402 47nF K 16V X7R 1
C1014 065G040247312K A 9JR6500000394 CAP CHIP 0402 47nF K 16V X7R 1
C1015 065G040247312K A 9JR6500000394 CAP CHIP 0402 47nF K 16V X7R 1
C1016 065G040239031J A 9JR6500000415 CAP CHIP 0402 39PF J 50V NPO 1
C1017 065G040239031J A 9JR6500000415 CAP CHIP 0402 39PF J 50V NPO 1
C1018 065G040233031J A 9JR6500000414 CAP 0402 33PF J 50V NPO 1
C1019 065G040233031J A 9JR6500000414 CAP 0402 33PF J 50V NPO 1
