Sharp LC-26SA1E Service Manual

LC-26SA1E/RU, LC-32SA1E/RU
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1119 VRS-TW2ED101JY AA J Resistor, 100 1/4W Metal Oxide
R1120 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R1121 VRS-TW2ED750JY AA J Resistor, 75 1/4W Metal Oxide
R1123 VRS-TW2ED750JY AA J Resistor, 75 1/4W Metal Oxide
R1125 VRS-TW2ED750JY AA J Resistor, 75 1/4W Metal Oxide
R1126 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R1127 VRS-TW2ED750JY AA J Resistor, 75 1/4W Metal Oxide
R1128 VRS-TW2ED101JY AA J Resistor, 100 1/4W Metal Oxide
R1129 VRS-TW2ED750JY AA J Resistor, 75 1/4W Metal Oxide
R1130 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R1131 VRS-CY1JF221JY AA J Resistor, 220 1/16W Metal Oxide
R1134 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1137 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R1138 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R1139 VRS-CJ1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R1140 VRS-CJ1JF331JY AA J Resistor, 330 1/16W Metal Oxide
R1141 VRS-CY1JF564JY AA J Resistor, 560k 1/16W Metal Oxide
R1142 VRS-CY1JF564JY AA J Resistor, 560k 1/16W Metal Oxide
R1143 VRS-CJ1JF272JY AA J Resistor, 2.7k 1/16W Metal Oxide
R1144 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1145 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1146 VRS-TV1JD221JY AA J Resistor, 220 1/16W Metal Oxide
R1147 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1148 VRS-TV1JD221JY AA J Resistor, 220 1/16W Metal Oxide
R1150 VRS-CY1JF104JY AA J Resistor, 100k 1/16W Metal Oxide
R1152 VRS-CJ1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R1153 VRS-CY1JF104JY AA J Resistor, 100k 1/16W Metal Oxide
R1154 VRS-CY1JF104JY AA J Resistor, 100k 1/16W Metal Oxide
R1155 VRS-CJ1JF331JY AA J Resistor, 330 1/16W Metal Oxide
R1156 VRS-CY1JF564JY AA J Resistor, 560k 1/16W Metal Oxide
R1157 VRS-CY1JF564JY AA J Resistor, 560k 1/16W Metal Oxide
R1158 VRS-CJ1JF272JY AA J Resistor, 2.7k 1/16W Metal Oxide
R1159 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1160 VRS-CY1JF102JY AA J
Resistor, 1k 1/16W Metal Oxide
R1161 V
RS-CY1JF221JY AA J Resistor, 220 1/16W Metal Oxide
R1173 VRS-CY1JF104JY AA J Resistor, 100k 1/16W Metal Oxide
R1177 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1179 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1201 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R1202 VRS-CY1JF392JY AA J Resistor, 3.9k 1/16W Metal Oxide
R1203 VRS-CY1JF682JY AA J Resistor, 6.8k 1/16W Metal Oxide
R1204 VRS-CY1JF750JY AA J Resistor, 75 1/16W Metal Oxide
R1206 VRS-TW2ED750JY AA J Resistor, 75 1/4W Metal Oxide
R1209 VRS-TW2ED750JY AA J Resistor, 75 1/4W Metal Oxide
R1210 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1211 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1212 VRS-CY1JF104JY AA J Resistor, 100k 1/16W Metal Oxide
R1213 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1214 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1215 VRS-CY1JF104JY AA J Resistor, 100k 1/16W Metal Oxide
R1216 VRS-CY1JF271JY AA J Resistor, 270 1/16W Metal Oxide
R1217 VRS-CY1JF331JY AA J Resistor, 330 1/16W Metal Oxide
R1218 VRS-CY1JF272JY AA J Resistor, 2.7k 1/16W Metal Oxide
R1219 VRS-CY1JF271JY AA J Resistor, 270 1/16W Metal Oxide
R1221 VRS-CY1JF331JY AA J Resistor, 330 1/16W Metal Oxide
R1222 VRS-CY1JF272JY AA J Resistor, 2.7k 1/16W Metal Oxide
R1224 VRS-CY1JF564JY AA J Resistor, 560k 1/16W Metal Oxide
R1225 VRS-CY1JF564JY AA J Resistor, 560k 1/16W Metal Oxide
R1226 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1227 VRS-CY1JF102JY AA J Resistor, 1k 1/16W Metal Oxide
R1228 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
SC301 QSOCZ0738CEZZ AE J Socket, 7Pin
[4] DUNTKD605FM10/FM11 (POWER Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
!
C704 RC-FZA026WJZZ AE J Capacitor, 0.47 275V
C705 RC-EZA985WJZZ AR N J Capacitor, 220 400V Electrolytic (LC-32SA1E/F/I
C706 RC-EZA985WJZZ AR N J Capacitor, 220 400V Electrolytic (LC-32SA1E/F/I
C707 RC-EZA979WJZZ AV J Capacitor, 330 400V Electrolytic (LC-26SA1E/F/I
!
C708 RC-KZ0105GEZZ AD J Capacitor, 2200p 250V Ceramic
!
C709 RC-KZ0105GEZZ AD J Capacitor, 2200p 250V Ceramic
!
C712 RC-FZA026WJZZ AE J Capacitor, 0.47 275V
C713 RC-KZA388WJZZY AC J Capacitor, 10 6.3V Ceramic
C716 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C717 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C720 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C722 VCCCCY1HH470JY AA J Capacitor, 47p 50V Ceramic
C723 RC-EZA489WJZZ+ AC J Capacitor, 47 35V Electrolytic
C725 RC-KZA304WJZZ AD N J Capacitor, 470p 2kV Ceramic
C726 VCCCCY1HH101JY AA J Capacitor, 100p 50V Ceramic
C728 VCKYCY1HB332KY AA J Capacitor, 3300p 50V Ceramic
C730 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C732 VCKYCY1HB104KY AA J Capacitor, 0.1 50V Ceramic
C733 VCKYCY1HB222KY AA J Capacitor, 2200p 50V Ceramic
C734 RC-KZA304WJZZ AD N J Capacitor, 470p 2kV Ceramic
[3] DUNTKD604FM12/FM13 (AV Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
