Sharp LC-26SA1E Service Manual

LC-26SA1E/RU, LC-32SA1E/RU
10
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
N LX-BZA165WJZZ J Screw, x2 (for Inlet)
[5] DUNTKD606FMV0 (OPERATION Unit)
D151 RH-EX0641GEZZY AA J Zener Diode, MTZJT-7212C
P153 QPLGNA057WJZZ AB J Plug, 3Pin(KM)
R151 VRD-RA2BE182JY AA J Resistor, 1.8k 1/8W Carbon
R152 VRD-RA2BE431JY AA N J Resistor, 430 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor, 8.2k 1/8W Carbon
R155 VRD-RA2BE432JY AA N J Resistor, 4.3k 1/8W Carbon
R156 VRD-RA2BE911JY AA N J Resistor, 910 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch, CH UP
S152 QSW-K0003AJZZ+ AB J Switch, CH DOWN
S153 QSW-K0003AJZZ+ AB J Switch, MENU
S154 QSW-K0003AJZZ+ AB J Switch, VOL UP
S155 QSW-K0003AJZZ+ AB J Switch, VOL DOWN
S156 QSW-P0035GEZZ AF J Switch
[6] DUNTKD607FMV0 (R/C,LED Unit)
C101 VCEASY1CN107MY AC J Capacitor, 100 16V Electrolytic
C102 VCKYTV1CF225ZY AB J Capacitor, 2.2 16V Ceramic
C104 VCEASX1CN106MY AC J Capacitor, 10 16V Electrolytic
C105 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
D101 RH-EXA092WJZZY AB J Zener Diode, UDZSTE-1712B
D102 RH-PX0202TAZZY AC J LED, PG1102W-330-TR
D103 RH-PX0210TAZZY AC J LED, BRPG1211C-TR
D104 RH-PX0419CEZZY AC J LED, SML-010LTT86
IC101 VHITPS850++-1Y AG J IC, TPS850
P101 QPLGNA344WJZZY AD J Plug, 10Pin(RA)
R101 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R108 VRS-CY1JF271JY AA J Resistor, 270 1/16W Metal Oxide
R109 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R112 VRS-CY1JF471JY AA J Resistor, 470 1/16W Metal Oxide
R114 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE N J Remote Receiver
SLD101 PSLDM4646CEFW AD J Shield
[7] DUNTKD608FM06/FM07 (TUNER Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
C201 VCESKA1AM336M+ AC J Capacitor, 33 10V Electrolytic
C202 VCCCCY1HH220JY AA J Capacitor, 22p 50V Ceramic
C203 VCCCCY1HH220JY AA J Capacitor, 22p 50V Ceramic
C204 VCESKA1CM477M+ AD J Capacitor, 470 16V Electrolytic
C205 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C206 VCESKA1CM107M+ AC J Capacitor, 100 16V Electrolytic
C207 VCESKA1HM106M+ AC J Capacitor, 10 50V Electrolytic
C208 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C209 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C210 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C211 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C212 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C213 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C214 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C215 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C216 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C217 VCESKA1HM106M+ AC J Capacitor, 10 50V Electrolytic
C218 VCKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C219 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C220 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C221 VCESKA1CM107M+ AC J Capacitor, 100 16V Electrolytic
C222 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C223 VCCCCY1HH391JY AB J Capacitor, 390p 50V Ceramic
C224 VCKYTV1CB224KY AB J Capacitor, 0.22 16V Ceramic
C225 VCKYCY1HB152KY AA J Capacitor, 1500p 50V Ceramic
C226 VCESKA1AM227M+ AD J Capacitor, 220 10V Electrolytic
C227 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C228 VCKYTV1CB474KY AC J Capacitor, 0.47 16V Ceramic
C229 VCCCCY1HH120JY AA J Capacitor, 12p 50V Ceramic
C230 VCESKA1HM106M+ AC J Capacitor, 10 50V Electrolytic
C231 VCKYCY1HF103ZY AA J Capacitor, 0.01 50V Ceramic
C232 VCCCCY1HH330JY AA J Capacitor, 33p 50V Ceramic
C233 VCKYCY1HB102KY AA J Capacitor, 1000p 50V Ceramic
C234 VCKYCY1EF104ZY AA J
Capacitor, 0.1 25V Ceramic
C235 V
CKYCY1HB103KY AA J Capacitor, 0.01 50V Ceramic
C236 VCCCCY1HH8R0DY AA J Capacitor, 80p 50V Ceramic
D201 VHD1SS390++-1Y AB J Diode, 1SS390TE61
D202 RH-EX0677GEZZY AC J Zener Diode, MTZJT-7233D
D203 VHD1SS390++-1Y AB J Diode, 1SS390TE61
D204 VHD1SS390++-1Y AB J Diode, 1SS390TE61
D205 VHD1SS390++-1Y AB J Diode, 1SS390TE61
D206 VHD1SS390++-1Y AB J Diode, 1SS390TE61
FB201 RBLN-A215WJZZY AB N J Balun, BLN-A215WJ
FB202 RBLN-0065CEZZY AC J Balun, BLN-0065CE
FL201 RFILC0278BMZZ AM J Filter
FL202 RFILC0294BMZZ AR J Filter
IC201 VHITDA9886+-1Y AV J IC, TDA9886TS/V4
[4] DUNTKD605FM10/FM11 (POWER Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
