Sharp LC-26SA1E Service Manual

LC-26SA1E/RU, LC-32SA1E/RU
11
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
L201 VPCNN1R2JR58NY AB J Coil, Peaking 1.2µH
L202 VPCNN1R2JR58NY AB J Coil, Peaking 1.2µH
L203 VP-MK100J0000+ AB J Coil, Peaking 10µH
L204 VP-MK120J0000+ AB J Coil, Peaking 12µH
L205 VPCNN330J4R2NY AC J Coil, Peaking 33µH
LUG201 QLUGHA002WJZZ AB J Lug
LUG202 QLUGHA002WJZZ AB J Lug
LUG203 QLUGHA002WJZZ AB J Lug
P201 QCNCMA012WJZZ AD J Connector, 15Pin
Q201 VS2SC2735//1EY AC J Transistor, 2SC2735JC21TL
Q202 VS2SC2735//1EY AC J Transistor, 2SC2735JC21TL
Q203 VS2SC3928AR-1Y AB J Transistor, 2SC3928A-T112-1R
Q204 VS2SA1530AR-1Y AB J Transistor, 2SA1530A-T112-1R
R201 VRS-CY1JF104JY AA J Resistor, 100k 1/16W Metal Oxide
R202 VRS-CY1JF681JY AA J Resistor, 680 1/16W Metal Oxide
R203 VRS-CY1JF683JY AA J Resistor, 68k 1/16W Metal Oxide
R204 VRS-CY1JF123JY AA J Resistor, 12k 1/16W Metal Oxide
R205 VRS-CY1JF473JY AA J Resistor, 47k 1/16W Metal Oxide
R206 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
R207 VRS-CY1JF470JY AA J Resistor, 47 1/16W Metal Oxide
R208 VRS-CY1JF470JY AA J Resistor, 47 1/16W Metal Oxide
R209 VRS-CY1JF123JY AA J Resistor, 12k 1/16W Metal Oxide
R210 VRS-CY1JF680JY AA J Resistor, 68 1/16W Metal Oxide
R211 VRS-CY1JF680JY AA J Resistor, 68 1/16W Metal Oxide
R212 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R213 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R214 VRS-CY1JF820JY AA J Resistor, 82 1/16W Metal Oxide
R215 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R216 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R217 VRS-CY1JF122JY AA J Resistor, 1.2k 1/16W Metal Oxide
R218
VRS-CY1JF122JY AA J R
esistor, 1.2k 1/16W Metal Oxide
R219 VRS-CY1JF222JY AA J Resistor, 2.2k 1/16W Metal Oxide
R220 VRS-CY1JF392JY AA J Resistor, 3.9k 1/16W Metal Oxide
R221 VRS-CY1JF392JY AA J Resistor, 3.9k 1/16W Metal Oxide
R223 VRS-CY1JF562JY AA J Resistor, 5.6k 1/16W Metal Oxide
R224 VRS-CY1JF562JY AA J Resistor, 5.6k 1/16W Metal Oxide
R226 VRS-CY1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R227 VRS-CY1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R228 VRS-CY1JF223JY AA J Resistor, 22k 1/16W Metal Oxide
R229 VRS-CY1JF223JY AA J Resistor, 22k 1/16W Metal Oxide
R230 VRS-CY1JF562JY AA J Resistor, 5.6k 1/16W Metal Oxide
R231 VRS-TQ2BD330JY AA J Resistor, 33 1/8W Metal Oxide
R232 VRS-CY1JF331JY AA J Resistor, 330 1/16W Metal Oxide
R233 VRS-CY1JF821JY AA J Resistor, 820 1/16W Metal Oxide
R234 VRS-CY1JF271JY AA J Resistor, 270 1/16W Metal Oxide
R235 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R236 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R237 VRS-CY1JF331JY AA J Resistor, 330 1/16W Metal Oxide
R238 VRS-CY1JF151JY AA J Resistor, 150 1/16W Metal Oxide
R239 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R240 VRS-CY1JF331JY AA J Resistor, 330 1/16W Metal Oxide
R241 VRS-CY1JF103JY AA J Resistor, 10k 1/16W Metal Oxide
R242 VRS-CY1JF392JY AA J Resistor, 3.9k 1/16W Metal Oxide
R243 VRS-CY1JF101JY AA J Resistor, 100 1/16W Metal Oxide
R244 VRS-CY1JF221JY AA J Resistor, 220 1/16W Metal Oxide
R245 VRS-TW2ED561JY AA J Resistor, 560 1/4W Metal Oxide
R246 VRS-CY1JF331JY AA J Resistor, 330 1/16W Metal Oxide
R247 VRS-CY1JF1R0JY AA J Resistor, 1 1/16W Metal Oxide
R248 VRS-CY1JF1R0JY AA J Resistor, 1 1/16W Metal Oxide
RJ1 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RJ2 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RJ3 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RJ4 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
RJ5 VRS-CY1JF000JY AA J Resistor, 0 1/16W Metal Oxide
SLD201 P
SLDMA898WJFW AD N J Tuner If Shield
X201 RCRSAA029WJZZ AF J Crystal
N LHLDW1072GEZZ AA J Wire Holder
[8] DUNTKD890FM12/FM13 (MAIN Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
C1702 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1706 RC-KZA070WJZZY AD J Capacitor, 22 6.3V Ceramic
C1715 VCEASX1VN226MY AC J Capacitor, 22 35V Electrolytic
C1716 VCEASX1CN226MY AC J Capacitor, 22 16V Electrolytic
C1717 VCKYCY1HB272KY AA J Capacitor, 2700p 50V Ceramic
C1718 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1720 VCEASX1CN226MY AC J Capacitor, 22 16V Electrolytic
C1721 VCAAPD1AJ686MY AE J Capacitor, 68 10V Electrolytic
C1723 RC-KZA073WJZZY AD J Capacitor, 10 16V Ceramic
C1724 RC-KZA073WJZZY AD J Capacitor, 10 16V Ceramic
C1726 RC-KZA070WJZZY AD J Capacitor, 22 6.3V Ceramic
C1730 VCKYCY1HB272KY AA J Capacitor, 2700p 50V Ceramic
C1733 VCEASX1CN226MY AC J Capacitor, 22 16V Electrolytic
C1734 VCKYCY1EF104ZY AA J Capacitor, 0.1 25V Ceramic
C1735 VCAAPD1AJ686MY AE J Capacitor, 68 10V Electrolytic
C1737 RC-KZA073WJZZY AD J Capacitor, 10 16V Ceramic
[7] DUNTKD608FM06/FM07 (TUNER Unit) (LC-26SA1E/RU, LC-32SA1E/RU)
