Sharp LC-32LE600E Service Manual

LC-32/40/46LE600E/RU/S (1st Edition)
4 – 3
5. Adjustment process mode menu
The character string in brackets [ ] will appear as a page title in the adjustment process menu header.
Page Line Item Description Remarks (adjustment detail, etc.)
1/8
1 Main Version 1.14 Main microprocessor version
2 Boot Version 20090429.1.12 Boot version of the main microprocessor
3 T-CON Version 00 00 00 00 32 4C 32 B1 T-CON microprocessor version
4 CPLD Version xx CPLD Version for Backlight controller
5 INCH SIZE 32/40/46 Initial Setting of panel size
6 ERROR RESET NO [NO/YES] Lamp error reset. (Select “YES” and press “OK” key.)
7 STANDBY CAUSE 00 00 00 00 00 Error standby cause. Total operating time before error.
1) 00H 00M (5 times histories)
2) 00H 00M
3) 00H 00M
4) 00H 00M
5) 00H 00M
2/8
1 INDUSTRY INIT [NO/YES(E)/YES(I)/YES(F)/YES(R) Initialization to factory settings execution.
2 PUBLIC MODE OFF [OFF/ON] ON/OFF setting of hotel mode
3 I2C DATA 000000000000 Write and read of data in I2C BUS control IC.
4 I2C STATE WAIT [STANDBY/WAIT] Execution of write and read of I2C DATA
3/8
1 INSPECT USB TERM ENTER Reading inspection of USB memory terminal
2 HDMI CEC TEST ENTER HDMI CEC test
4/8
1 TUNER ADJ ENTER VIDEO level adjustment execution
2 CHANNEL E-12/E-9(SMPTE)/E-12(SMPTE)
3 GAIN 31 Gain adjustment
4 ADJ RESET NO [NO/YES] Reset of adjustment
5/8
1 VIDEO ADJ ENTER VIDEO level adjustment execution
2 GAIN 31
6/8
1 COM-ADJ ENTER COMPONENT level adjustment execution
2 Y OFF SET 70 Y CUTOFF adjustment value
3 PB OFF SET 128 PB CUTOFF adjustment value
4 PR OFF SET 128 PR CUTOFF adjustment value
5 Y GAIN 140 Y GAIN adjustment value
6 PB GAIN 140 PB GAIN adjustment value
7 PR GAIN 140 PR GAIN adjustment value
8 ADJ RESET NO [NO/YES] Reset of adjustment
7/8
1 RGB-ADJ ENTER SCART RGB level adjustment execution
2 R OFF SET 128 R OFF SET adjustment value
3 G OFF SET 128 G OFF SET adjustment value
4 B OFF SET 128 B OFF SET adjustment value
5 R GAIN 80 R DRIVE adjustment value
6 G GAIN 80 G DRIVE adjustment value
7 B GAIN 80 B DRIVE adjustment value
8 ADJ RESET NO [NO/YES] Reset of adjustment
8/8
1 COM BIAS 67 Common Bias auto adjustment execution
2 LCD TEST PATTERN 0 Pattern with built-in LCD controller display
3 WB Point A 1280 W/B adjustment, gradation Point A input setting
4 Point B 3712 W/B adjustment, gradation Point B input setting
5 Point A ADJ R 1280 W/B adjustment, gradation Point A R_adjustment value
6 ADJ G 1280 W/B adjustment, gradation Point A G_adjustment value
7 ADJ B 1280 W/B adjustment, gradation Point A B_adjustment value
8 Point B ADJ R 3712 W/B adjustment, gradation Point B R_adjustment value
9 ADJ G 3712 W/B adjustment, gradation Point B G_adjustment value
10 ADJ B 3712 W/B adjustment, gradation Point B B_adjustment value
11 WB WRITE NO [NO/YES] W/B writing of adjustment values
12 WB RESET NO [NO/YES] Reset of W/B adjustment value
