LC-32/40/46LE600E/RU/S (1st Edition)
ii
DIFFERENCES FROM BASE MODEL
LIST OF CHANGED PARTS (LC-32LE600E/RU/S)
Ref. No. Description
LC-32LE700E/RU/S
(No. S89B4LC32L700)
LC-32LE600E/RU/S
(No. S89B5LC32L600)
Note
PRINTED WIRING BOARD ASSEMBLIES
KEY Unit DUNTKE266FM18 ← —
MAIN Unit DUNTKE306FM01 DUNTKF111FM11 Changed
R/C, LED Unit DUNTKE308FM02 ← —
ICON Unit DUNTKF314FM02 — Abolish
POWER Unit RUNTKA619WJQZ ← —
LCD Control Unit RUNTK4225TPZE RUNTK4248TPZB Changed
LED5 PWB1 Unit RUNTKA595WJ01 ← —
LED5 PWB2 Unit RUNTKA595WJ02 ← —
LED8 PWB1 Unit RUNTKA598WJ01 ← —
LED8 PWB2 Unit RUNTKA598WJ02 ← —
LCD PANEL
32"LCD Panel Module R1LK315D3FZE0Y R1LK315D3FZF0Y Changed
CABINET AND MECHANICAL PARTS
1 Front Cabinet Ass’y CCABAC371WJ11 CCABAC371WJ12 Changed
1-4 Diffusion Sheet PSHEPB007WJKZ — Abolish
2 Rear Cabinet Ass’y CCABBB619WJ11 CCABBB619WJ12 Changed
2-2 Terminal Label HINDPD390WJSA HINDPD391WJSA Changed
4 Bottom Cover Ass’y CCOVAD472WJ11 — Abolish
5 Side Terminal Angle Ass’y CANGKC375WJ01 CANGKC375WJ02 Changed
5-1 Side Terminal Label HINDPD408WJSA HINDPD470WJSA Changed
8 Wire Holder LHLDWA289WJKZ, x3 LHLDWA289WJKZ, x2 Abolish (3→2)
18 Connecting Cord Main-Power(LB) QCNW-J915WJQZ QCNW-J896WJQZ Changed
19 Connecting Cord Main-Key(KM) QCNW-J977WJQZ — Abolish
20 Connecting Cord Main-R/C, LED(RA) QCNW-J976WJQZ — Abolish
21 Connecting Cord Main-Power(PL) QCNW-J898WJQZ QCNW-G182WJQZ Changed
22 Connecting Cord Main-LCD Control(LW) QCNW-J894WJQZ QCNW-K027WJQZ Changed
24 Connecting Cord Main-LCD Control(LP) QCNW-J897WJQZ QCNW-J712WJQZ Changed
25 Connecting Cord R/C, LED-ICON(IM) QCNW-J916WJQZ — Abolish
33 POP Label (except for Russia) TLABZC319WJZZ TLABZC352WJZZ Changed
33 POP Label (for Russia) TLABZC320WJZZ TLABZC353WJZZ Changed
35 Screw (for HDMI) XBPS730P06000, x4 XBPS730P06000, x3 Abolish (4→3)
N Bottom Cover — GCOVAD472WJ1A Addition
N Connecting Cord Main-R/C, LED-Key(RA/KM) — QCNW-J892WJQZ Addition
LCD PANEL MODULE UNIT
1-4 LCD Control Unit RUNTK4225TPZE RUNTK4248TPZB Changed
1-5 Screw XHPS730P06WS0, x6 XHPS730P06WS0, x4 Abolish (6→4)
1-22 32” LCD Panel Unit R1LK315D3FZE0Y R1LK315D3FZF0Y Changed
1-28 Screw LX-HZA039WJF7, x10 LX-HZA039WJF7, x8 Abolish (10→8)
N Washer Screw — LX-HZA064WJF7 Addition
SUPPLIED ACCESSORIES
X4 Stand Unit CDAi-A595WJ02 CDAi-A584WJ02 Changed
X5 Operation Manual (for Europe except East Europe) TiNS-E281WJZZ TiNS-E285WJZZ Changed
X5 Operation Manual (for Sweden) TiNS-E282WJZZ TiNS-E286WJZZ Changed
X5 Operation Manual (for East Europe) TiNS-E283WJZZ TiNS-E287WJZZ Changed
X5 Operation Manual (for Russia) TiNS-E284WJZZ TiNS-E288WJZZ Changed
SERVICE JIGS (USE FOR SERVICING)
Main+LCD Control-Power(LB) QCNW-K036WJQZ QCNW-K037WJQZ Changed
Main-Key(KM) QCNW-G440WJQZ — Abolish
Main-R/C, LED(RA) QCNW-H184WJQZ — Abolish
Main-R/C, LED-Key(RA/KM) — QCNW-K039WJQZ Addition
R/C, LED-ICON(IM) QCNW-G442WJPZ — Abolish
MAIN Unit
Please refer to a Parts list
