Sharp LC-40LX630E User Manual

164
LC-32LE63x
LC-40LE63x
LC-46LE63x
12.20.5 LC-32LU632 Mechanical Parts Listing
LC-32LU632 CABINET AND MECHANICAL PART LISTING
PRICE
1 CCABAC768WJ01 KS-CAB-A LC32. P --
2 GCABAC768WJ1A FRONT CABINET P --
3 GCABBB982WJ1A REAR CABINET P --
4 313912139021 VESA BRACKET TOP P --
5 313913401841 VESA BRACKET BOTTOM P --
6 R1LK315D3LA63Y 32" LCD MODULE LK315D3LA63 P --
7 TLABZC453WJZZ PANEL LABEL (Except Russian models) (DLAB-D933WE01) P --
8
313912139461
TERMINAL COVER SIDE
P
--
REF No. PARTS DESCRIPTION * CODE
8
313912139461
TERMINAL
COVER
SIDE
P
--
9 313912138942 TERMINAL COVER BOTTOM P --
10 LANGKD336WJFW STAND BRACKET P --
11 313912139031 PANEL BRACKET TOP P --
12 313912139051 PANEL BRACKET SIDE P --
13 313912139001 PANEL BRACKET BOTTOM P --
14 313912139011 TWEETER BRACKETS P --
15 313917105791 FFC FI-R 41P LVDS (313929712631) P --
16 313917105861 FFC FI-R 51P LVDS (313929712631) P --
17 RUNTKA865WJPA2 CONTROL BUTTON UNIT P --
18 310431119961 WIRE (HL) P --
19 313912326761 EMC FOAM 6,5x20 L100MM P --
20 313912326771 EMC FOAM 4x10 L10MM P --
21 313917105561 WIRE (VT) 2P/120+120+140/INLET+SDDJF P --
22 313913401041 POWER SWITCH AND INLET HOLDER BRACKET P --
23 313912326591 BARRIER SHEET P --
24 242201520149 PIN PUSH NY6/6FR GN 14.5MM B (x2) P --
25
242226440104
SPEAKER TWEETERS (12R 5W OPN TWEE R29 EU 32
"
B)
P
--
25
242226440104
SPEAKER
TWEETERS
(12R
5W
OPN
TWEE
R29
EU
32
B)
P
--
26 242226440079 SPEAKER SUBWOOFER (24R 10W BOX1115M-AB) P --
27 313913401061 CABLE TIE P --
28 TLABNE414WJZZ
MODEL LABEL (DLAB-E045WE01)
P--
29 TLABZC993WJZZ POP LABEL P --
30 TLABZC881WJZZ CE ENERGY LABEL P --
31 242201500193 SADDLE WIRE NY66 NT 11.5 WIRE HOLDER P --
32 251107655012 SCREW WASH PAN TORX STZN BK M3x8 (x2) P --
33 252220000092 SCREW PAN TORX ST ZN BK M3x6 (x47) P --
34 313912041192 SCREW FLANGE TORX 1.8 PLASTITE (x5) P --
35 252270098344 SCREW HOLE PLUG TAPPED NY 6.6 BK M6 (x4) P --
36 CDAI-A794WJ01 KS-STAND P --
37
QACCKA047WJPZ
AC cord PE8C5Z1B90A-05B 2 5A 1 8M
P
--
PRICE
CODE
ACCESSORIES PARTS LISTING
REF No. PARTS DESCRIPTION *
37
QACCKA047WJPZ
AC
cord
PE8C5Z1B90A
-
05B
2
,
5A
1
,
8M
P
--
38 TINS-F125WJZZ QUICK START GUIDE P --
39
908210090001
BATTERY R03-B500/01S P --
40
313913872431
SCREW for STAND P --
41
TINS-F203WJZZ
SAFETY SHEET P --
42
313912568771
TRACEABILITY LABEL P --
43
314302620392
O/M PE BAG P --
44
RRMCGA965WJSA
REMOTE CONTROL LE63*E P --
45 RRMCGA968WJSA Optional 2nd. REMOTE CONTROL LU63*E P --
46 SPAKCG377WJZZ Packing Case. P --
47 SPAKPB437WJZZ Packing bag. P --
48 SPAKXD411WJZZ Pack-AD (EPS) TOP P --
49 SPAKXD412WJZZ Pack-AD (EPS) BOTTOM P --
PRICE
CODEREF No. PARTS DESCRIPTION *
PACKING PARTS LISTING

Sharp LC-40LX630E Specifications

General

Response time	6 ms
Display diagonal	40 \
Display brightness	450 cd/m²
Native aspect ratio	16:9
Native refresh rate	100 Hz
LED backlighting type	Edge-LED
Supported video modes	1080p
Display diagonal (metric)	102 cm
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
3D	No
Annual energy consumption	70 kWh
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-T
RMS rated power	10 W
Number of speakers	2
HDMI version	1.4
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	1
Video formats supported	H.264, MPEG4
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.15 W
Power consumption (typical)	48 W

Weight and Dimensions

Depth (with stand)	242 mm
Height (with stand)	630 mm
Weight (with stand)	14700 g
Depth (without stand)	40 mm
Width (without stand)	947 mm
Height (without stand)	560 mm
