29
LC-32LE63x
LC-40LE63x
LC-46LE63x
4.3.7 Removing of major Parts 32” (Continued)
4. Disconnect all the connectors from all the PWBs.
SPEAKER -R
(TWEETER)
SPEAKER -L
(TWEETER)
[1316] [1M95]
[1D38]
[1735]
[1G50]
[1G51]
[1M19]
TO DISPLAY
SUPPLY
[1M95]
SPEAKER
(SUBWOOFER)
[1308]
MAIN
SWITCH
INLET
MAIN UNIT
POWER UNIT
