RS-232C command table
How to read the command table
Command: Command eld (See page 35.)
Direction: W When the “Parameter” is set in the parameter eld (see page 35), the command functions as described
under “Control/Response Contents”.
R The returned value indicated under “Reply” can be obtained by setting “????”, “
?” or “???+”
(repeater control) in the parameter eld. (See page 35.)
Parameter: Parameter eld (See page 35.)
Reply: Response (Returned value)
* :
“●” indicates a command which can be used in standby mode regardless of the POWER SAVE MODE setting.
“○” indicates a command which cannot be used in standby mode when POWER SAVE MODE is set to ON.
“–” indicates a command which cannot be used in standby mode regardless of the POWER SAVE MODE setting.
Power control/Input mode selection
Function
Command Direction
Parameter Reply Control/Response contents *
POWER CONTROL POWR W 0 Switches to standby mode.
●
1 Returns from standby mode.
R 0 Standby mode
1 Normal mode
2 Input signal waiting mode
INPUT MODE SELECTION INPS W 0 Toggle change for input mode. Terminals not selected in INPUT SELECT
cannot be selected.
1 DVI-D
2 D-SUB[RGB]
“ERR” when other than RGB is selected for D-SUB of INPUT SELECT.
3 D-SUB[COMPONENT]
“ERR” when other than COMPONENT is selected for D-SUB of INPUT
SELECT.
10 HDMI1
13 HDMI2
14 DisplayPort
21 OPTION
“ERR” when nothing is attached in the expansion slot.
R 1 DVI-D
2 D-SUB[RGB]
3 D-SUB[COMPONENT]
10 HDMI1
13 HDMI2
14 DisplayPort
21 OPTION
