Shure MVI User Manual

Shure Incorporated
12/14
Specifications
MFi Certified
Yes
DSP Modes (Presets)
Speech/Singing/Acoustic/Loud/Flat
Input
CombinationXLRand6.35mm(1/4")TRS
Input Impedance
1/4inchinstrumentinput>1MΩ
Bit Depth
16-bit/24-bit
Sampling Rate
44.1/48kHz
Frequency Response
20Hzto20,000Hz[1]
Adjustable Gain Range
3-pin XLR 0to+36dB
6.35 mm (1/4") TRS +9dB
Maximum Input Level
3-pin XLR 0dBV[1]
6.35 mm (1/4") TRS +9dBV[1]
Headphone Output
3.5mm(1/8″)
Power Requirements
Powered through USB or Lightning connector
Phantom Power
+48V USB/+12V iOS
Mute Switch Attenuation
Yes
Housing
all metal construction

Shure MVI Specifications

General

DSP Modes	Speech, Singing, Flat, Acoustic Instrument, Loud
Bit Depth	24-bit
Sample Rate	48 kHz
Adjustable Gain Range	0 to +36 dB
Phantom Power Protection	Yes
Function	Digital audio interface
Material	Metal
Color	Black
Compatibility	iOS, Android, Mac
Frequency Response	20 Hz to 20 kHz
Power Requirements	USB-powered
Input	XLR
Output	3.5mm
