25A1104 (Rev.1)
RF BAND RESISTORS
Four resistors Ra, Rb, Rc, and Rd are responsible to start the microcontroller in a RF band.
Table 2 shows the reference designators and how the voltages at the test points reflect the operating RF band.
.
Table 3 shows the variant resistor installation options for each band. When a resistor is installed the microprocessor will read a logic low,
otherwise it will read a logic high..
Table 2
PG4 Reference Designators
Rd Rc Rb Ra
R316 R315 R314 R313
Table 3
RF BAND Board ID Rd Rc Rb Ra
H7 A
K7 B Installed
M7 C Installed
M10 D Installed Installed
P11 E Installed
Q11 F Installed Installed
R10 G Installed Installed
R11 H Installed Installed Installed
R12 J Installed
JB K Installed Installed
T10 L Installed Installed
Reserved M Installed Installed Installed
Reserved N Installed Installed
