SICK DR35 User Manual

Identication
16 © SICK AG • Subject to change without notice • 8014868/YIF1/2020-10-19
3.2 Type code
D T 3 5 – B 1 5 5 5 1 X
1 2 3 4 5 6 7 8 9 10 11
Position Description
1 … 4
Sub product family
DS35 Distance sensor, switching on natural objects
DT35 Distance sensor, measurement on natural objects
DL35 Distance sensor, measurement on reective tape
DR35 Distance sensor, switching on reective tape
5
Outputsignalswitchingdevice
B B-type or push-pull output
6
Speed, sensing range
1 Adjustable
7
Connection type
5 M12 plug, 5-pin
8
Light sender, laser class
2 Red light, laser class 2
5 Red light, laser class 1
8 Infrared light, laser class 1
9
Interface
2 Switching outputs Q1 and Q2 and IO-Link
5 Analog current or voltage output (Q2), switching output (Q1) and IO-Link
10
Measurement
1 Optimized for natural objects
2 Optimized for reective tape
11
Other info
X Additional characters possible
Table 1: “Dx35 distance sensor” type code
