1.5 Key features
- High screen resolution: 128 x 240 dots
- 6 keys for ease of operation
- Programmable menu with easy-to-understand structure
- Key ALARM, INFO and ESC with LED indicators
- Definable user password for every access level
- Support of multi-language and Unicode fonts
- Support of online trend, time scheduler and iconic mode function
- HMI local settings supported
- Data point access supported
- Powered by controller via local HMI connection
- Panel or magnetic mounting, hand-held operation
- Firmware can be updated via
controller (SD card support required)
1.6 Reference documents
The following documents contain further information on the products described in
this document:
Document
Document No.
1
Data Sheet “Climatix HMI-TM”
CB1N3917en
2
Mounting Instructions “Climatix HMI-TM”
CB1M3917en
3
CE declaration of conformity
CB1T3917xx
4
Environment product declaration (POL871.71)
233006-T-0601_EN
5
Environment product declaration (POL871.72)
233006-T-0602_EN
1.7 Product variant
HMI-TM variant
Cable
Hand-held and magnetic mounting
version POL871.71
3 m customized cable with 1 RJ45 plug and 1
slim connector (4-wire twisted pair)
(included in HMI box)
Panel mounting version POL871.72 1.5 m Cat-5 Ethernet cable with 2 RJ45 plugs
(8-wire twisted pair)
(included in HMI box)
