5 SPECIFICATIONS
The following is a basic specification for DigiTRON connectors. Actual product may vary. Please
refer to product specific data sheet(s), website https://www.siemens-energy.com /search Subsea, or
contact Siemens Energy Technical Support connectortechnicalsupport.gb@siemens-energy.com
for more detailed information.
General specification of the product is listed in section 2.2. Additional specifications are as follows.
5.1 Connector Specification
ROV operated
Stab-plate
Diver operated
Misalignment
Type
4 & 7-way
12-way
4 & 7-way
12-way
4 & 7-way
12-way
Rotational (0º)
±15º
±15º
±1.6º
±1.6º
n/a
n/a
Radial
±20mm
(0.787”)
±20mm
(0.787”)
±1mm
(0.039”)
±1mm
(0.039”)
n/a
n/a
Angular
±20º
±20º
±0.7º
±0.7º
n/a
n/a
Mate force
<300N
(67 lb)
<500N
(112 lb)
<300N
(67 lb)
<500N
(112 lb)
Integral clamp ring
Demate force
240 – 360N
(54 – 81 lb)
480-800N
(108 - 179lb)
0
0
0
0
Overload
withstand
Axial load
9800N
(2,198 lb)
9800N
(2,198 lb)
9800N
(2,198 lb)
9800N
(2,198 lb)
n/a
n/a
Bending load
500Nm
(369 lbf.ft)
500Nm
(369 lbf.ft)
n/a
n/a
n/a
n/a
Torsion load
500Nm
(369 lbf.ft)
500Nm
(369 lbf.ft)
n/a
n/a
n/a
n/a
Maximum mate /
de-mate speeds
1 m/s
(3.3 ft/s)
1 m/s
(3.3 ft/s)
1 m/s
(3.3 ft/s)
1 m/s
(3.3 ft/s)
1 m/s
(3.3 ft/s)
1 m/s
(3.3 ft/s)
Limit of exposure of male pins to seawater 28 days cumulative over lifetime
Table 5 DigiTRON connector specification
