2.2 Product specification and certification
Basic specifications relating to all products covered by this manual are below in Table 3. Additional
specifications can be found in section 5.
30 years in subsea environment
DigiTRON+ 1,000Vac pin-ground, 2,000Vac pin-pin
DigiTRONe Ethernet lines 50Vdc, other lines as DigiTRON+
DigiTRON3 1,800Vac pin-ground, 2,000Vac pin-pin
In water: 4-way 35-40A 7-way 22-32A 12-way 20-28A
In air: 4-way 18A 7-way 14A 12-way 11A
(Excludes ethernet lines)
100A for 5 seconds, no more than 2 per hour
Rated number of
operations
1000 (750dry/250wet) mate / de-mate cycles (Power off)
-40°C +70°C (-40°F +158°F) (upper limit is surface temperature of the
product and includes solar gain from bright sunlight)
Subsea: -5°C +60°C (+23°F +140°F)
In air: -20°C +50°C (-4°F +122°F)
Connectors - Safety requirements and tests
Standard for Subsea Production Control Systems
Note: Self-certified via in-house testing.
Table 3 DigiTRON product specification and certification
