Replacement parts
8.9 Terminal box 1XB1 631
A5E01083943A AB
98 Siemens AG Operating Instructions 2.02 1FW4
8.9 Terminal box 1XB1 631
Replacement parts
;
;
Figure 8-7 Terminal box 1XB1631
Table 8-7 Spare parts list for terminal box 1XB1631
Part Description Part Description
20.20 Housing 20.70 Sealing insert for cable entry
20.30 Cover 20.86 Entry for auxiliary cable
20.38 Sealing cover 21.11 Connecting plate with internal cable
20.61 Cable gland (upper part) 21.41 Terminal supports
20.62 Cable gland (lower part) 21.61 Terminal strip for auxiliary circuit
20.65 Strain relief (upper part) 22.05 Terminal body
20.65.1 Socket head cap screw DIN 912, M8 22.07 Terminal strip
