ISGS Settings Worksheet for Date: Set B
S-18 Siemens Energy & Automation, Inc.
B1500
Instantaneous Phase Overcurrent (50)
High-Set Instantaneous Phase Overcurrent (50HS)
B1501 Function 50 Enabled Disabled
B1502 Pickup 50 5 A CT 1.0 A Range: 1-120 A (0.1 A steps) A
1 A CT 0.2 A Range: 0.2-24 A (0.1 A steps) A
B1504 Time Delay 50 0.00 s Range: 0-60 s (0.01 s steps) s
1510 Freeze Waveform 1 50 Settings displayed or changed here apply to both parameter sets
1511 Freeze Waveform 2 50 Settings displayed or changed here apply to both parameter sets
B1512 Block 50 by None 50HS & 50HSN 50HS 50HSN
B1551 Function 50HS Enabled Disabled
B1552 Pickup 50HS 5 A CT 5.0 A Range: 5-120 A (0.1 A steps) A
1 A CT 0.2 A Range: 0.2-24 A (0.1 A steps) A
1560 Freeze Waveform 1 50HS Settings displayed or changed here apply to both parameter sets
1561 Freeze Waveform 2 50HS Settings displayed or changed here apply to both parameter sets
B1600
Instantaneous Neutral or Ground Overcurrent (50N)
High-Set Instantaneous Neutral or Ground Overcurrent (50HSN)
B1601 Function 50N Enabled Disabled
B1602 Pickup 50N 5 A CT 1.0 A Range: 1-120 A (0.1 A steps) A
1 A CT 0.2 A Range: 0.2-24 A (0.1 A steps) A
B1604 Time Delay 50N 0.00 s Range: 0-60 s (0.01 s steps) s
1610 Freeze Waveform 1 50N Settings displayed or changed here apply to both parameter sets
1611 Freeze Waveform 2 50N Settings displayed or changed here apply to both parameter sets
B1612 Block 50N by None 50HS & 50HSN 50HS 50HSN
B1651 Function 50HSN Enabled Disabled
B1652 Pickup 50HSN 5 A CT 5.0 A Range: 5-120 A (0.1 A steps) A
1 A CT 0.2 A Range: 0.2-24 A (0.1 A steps) A
1660 Freeze Waveform 1 50HSN Settings displayed or changed here apply to both parameter sets
1661 Freeze Waveform 2 50HSN Settings displayed or changed here apply to both parameter sets
S
