Migration from MC35 to MC35i
PRELIMINARY
Migration from MC35 to MC35i
14 of 30 12.03.03
4.4.2 Power up / down scenarios
MC35 and MC35i are fully identical regarding the power up/down scenario.
4.4.3 Automatic shutdown
To ensure proper operation of all assemblies under varying conditions, such as temperature,
input voltage, transmission power etc., MC35 and MC35i features protection elements for
automatic shutdown.
Automatic shutdown takes effect if:
æ the MC35/MC35i board is exceeding the critical limits of overtemperature or undertemperature
æ the battery is exceeding the critical limits of overtemperature or undertemperature
æ undervoltage is detected
æ overvoltage is detected.
4.4.3.1 Temperature dependent shutdown
The board temperature is constantly monitored by an internal NTC resistor located on the
PCB. The values detected by NTC resistor are measured directly on the board and are
therefore not fully identical with the ambient temperature.
Table 8: Maximum ratings and the associated URCs
Sending temperature alert
MC35 MC35i
^SCTM_A: 1 Caution: T
amb
of battery between +56°C and +60°C.
^SCTM_B: 1 Caution: T
amb
of board between +65°C and +70°C. Caution: T
amb
of board between +65°C and +70°C.
^SCTM_A: -1 Caution: T
amb
of battery between -14°C and –18°C.
^SCTM_B: -1 Caution: T
amb
of board between –26°C and –29°C. Caution: T
amb
of board between –26°C and –29°C.
^SCTM_A: 0 Battery back to uncritical temperature range
^SCTM_B: 0 Board back to uncritical temperature range.
Automatic shutdown (URC appears no matter whether or not presentation was enabled)
^SCTM_A: 2 Alert: T
amb
of battery >60°C. MC35 switches off
immediately.
^SCTM_B: 2 Alert: T
amb
of board >70°C. MC35 switches off
immediately.
Alert: T
amb
of board >70°C. MC35i switches off
immediately.
^SCTM_A: -2 Alert: T
amb
of battery < -18°C. MC35 switches off
immediately
^SCTM_B: -2 Alert: T
amb
of board <-29°C. MC35 switches off
immediately.
Alert: T
amb
of board <-29°C. MC35i switches off
immediately.
